Sharp AF-W12CME - Installation Instructions; Part Names and Dimensions; Items Packed with this Unit

14
BATTERY
REMOTE CONTROL
DRAIN TRAY
GASKET
GOLD SCREW (2.5cm/1")
GOLD SCREW (1.2cm/0.5")
The long GOLD SCREW ( ) is used to secure the cabinet to the mounting frame.
The short GOLD SCREW ( ) is used to secure the drain tray to the cabinet.
The DRAIN TRAY ( ) is attached to the cabinet, in case drainage is necessary in high humidity
district.See page 16 for detail installation instructions.
ITEMS PACKED WITH THIS UNIT
Q'ty
Accessories
9
2
1
1
1
2
1
2
3
4
5
6
1
2
4
1
2
4
3
5
6
PART NAMES AND DIMENSIONS
Front panel
Grille
Air filter (behind the grille)
Up/Down air flow adjustment louvers
Left/Right air flow adjustment louvers
Cabinet
Ventilation lever
Control panel
Stopper screws
(on left and right side)
Power cord
Remote control
We reserve the right to change the materials and specifications without notice.
DIMENSIONS
A (mm)
C (mm)
B (mm)
D (mm)
E (mm)
375
560
600 (center 610)
255
30 (center 40)
)
*
+
-
,
1
2
3
4
5
6
7
8
9
10
11
INSTALLATION INSTRUCTIONS
