2-2 Frequency control
(1) AC current peak control
(2) Control for prevention of indoor heat exchanger overheating. If the temperature of the indoor heat exchanger
exceeds the overheating prevention line 1 or 2 during heating, the operating frequency is lowered by approximately
5 to 10 Hz. After that, the frequency is lowered by approximately 5Hz once every 60 seconds or 10 Hz once every
120 seconds. When the temperature of the indoor heat exchanger goes below the overheating prevention line 1,
the frequency is raised by approximately 5 Hz once every 60 seconds, and normal operation is restored.
If the frequency is lowered to minimum frequency without the temperature of the outdoor heat exchanger
decreasing and this condition lasts for 1 minute, the compressor will be stopped.
(3) Control for prevention of outdoor heat exchanger overheating. If the temperature of the outdoor heat exchanger
exceeds the overheating prevention lone 1 or 2 during cooling, the operating frequency is lowered by approximately
5 to 15 Hz.
After that, the frequency is lowered by approximately 5 once every 60 seconds or approximately 15Hz once every
120 seconds. When the temperature of the outdoor heat exchanger goes below the overheating prevention clear
line, the frequency is raised by approximately 5 Hz once every 60 seconds, and normal operation is restored. If the
frequency is lowered to minimum frequency without the temperature of the outdoor heat exchanger decreasing and
this condition lasts for 1 minute, the compressor will be stopped.
4) Control for prevention of discharge overheating
If the discharge temperature exceeds approximately (AU-X13BE:101°C except AU-X13BE:105°C) during compressor
operation, the operating frequency is lowered by approximately 5 Hz. After that, the frequency is lowered by
approximately 5 Hz once every 60 seconds. When the discharge temperature goes below approximately (AU-
X13BE:100°C except AU-X13BE:104°C) , the frequency is raised by approximately 5 Hz once every 60 seconds,
and normal operation is restored.
If the frequency is lowered to minimum frequencywithout the discharge temperature decreasing and this condition
lasts for 1 minute, the compressor will be stopped.
Frequency A B C D E F G
AE-X08BE 92 88 83 75 50 43 37
AE-X10BE 120 113 107 100 50 43 37
AE-X13BE 120 113 107 100 50 43 37
AE-X08BE-C 101 100 90 85 50 45 40
AE-X10BE-C 114 109 103 97 50 43 37
A~ A~B B~C C~D D~E E~F F~G ~G
A~ A~B B~C C~D D~E E~F F~G ~G
During normal operation
[°C]
[°C]
[°C]
[°C]
46.11 49.59 51.87 53.29 54.26 53.29 52.34 51.41
During full power operation 49.14 51.87 54.75 56.25 58.32 56.76 55.74 54.26
During normal operation 48.26 51.87 51.87 55.24 56.25 55.24 54.26 53.29
During full power operation 51.41 51.87 53.77 58.32 59.94 58.32 57.27 56.25
Operating Frequency
Operating Frequency
Overheating prevention line 1(Lower 5Hz)
Overheating prevention line 2(Lower 10Hz)
56˚C
58˚C
55˚C
Lower 5Hz once every 60 seconds
Lower 15Hz once every 120 seconds
Overheating prevention line 1
Overheating prevention line 1
Overheating prevention line 1
Model
Set valve
Cool Heat
6.0A 7.5A
5.0A 5.5A
7.0A 8.5A
5.0A
5.5A
7.0A
AE-X08BE
AE-X10BE
4.3A 4.5A
AE-X08BE-C
5.2A 5.7A
AE-X10BE-C
AE-X13BE
AU-X08BE
AU-X10BE
AU-X13BE
