Sharp AH-X08BE Service Manual

2
AH-X08BE/10BE/13BE
AY-X08BE/10BE/13BE
AY-X08BE-C/10BE-C
AU-X08BE/10BE/13BE
AE-X08BE/10BE/13BE
AE-X08BE-C/10BE-C
SPECIFICATIONS
MODEL
I NDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
ITEMS AH-X08BE AU-X08BE AH-X10BE AU-X10BE AH-X13BE AU-X13BE
Cooling capacity (Min. ~ Max.) kW 2.2(0.9
_
2.7) 2.8(0.9
_
3.3) 3.6(0.9
_
4.2)
Moisture removal Liters/h 0.6 0.7 1.3
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Rated current A 3.4
_
3.1 4.3
_
4.0 5.5
_
5.1
Rated input W 730 930 1200
Power factor % 98
_
98 98
_
97 99
_
98
Type Hermetically sealed rotary type
Compressor Model 2RV110N5EA04 HV237A1-S15DK
Oil charge ATMOS M60 or SUNISO 4GDID 260 cm
3
SUNISO 4GSD 455 cc
Evaporator Bare tube type Grooved tube type Grooved tube type
Refrigerant system Condenser Louver Fin and Grooved tube type
Control Capillary tube
Refrigerant volume 550g 550g 830g
Noise level
High dB(A) 33 43 36 43 38 48
(at cooling)
Med. dB(A) 29 – 32 – 33 -
Low dB(A) 27 – 27 – 29 -
Fan system
Drive Direct drive
Air flow quantity High m
3
/min. 7.5 28 8.7 28 9.3 30
(at cooling) Med. m
3
/min. 6.8 – 7.8 – 8.1 –
Low m
3
/min. 6.0 – 6.0 – 6.6 –
Fan Cross flow fan Propeller fan Cross flow fan Propeller fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4"
Drain piping mm O.D ø 18
Others
Compressor: Thermal protector
Safety device Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Width mm 815 780 815 780 815 780
Net dimensions Height mm 278 540 278 540 278 540
Depth mm 198 269 198 269 198 269
Net weight kg 9 31 9 33 10 38
Note: The condition of star " " marked item are ‘ISO5151’ : 1994(E), condition T1.
