Sharp AH-X08BE Service Manual

3
AH-X08BE/10BE/13BE
AY-X08BE/10BE/13BE
AY-X08BE-C/10BE-C
AU-X08BE/10BE/13BE
AE-X08BE/10BE/13BE
AE-X08BE-C/10BE-C
MODEL
I NDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
ITEMS AY-X08BE AE-X08BE AY-X08BE-C AE-X08BE-C
Cooling capacity (Min. ~ Max.) kW 2.2(0.7
_
2.7) 2.2(0.9
_
2.7)
Heating capacity (Min. ~ Max.) kW 3.2(0.7
_
3.6) 3.2(0.9
_
3.6)
Moisture removal(at cooling) Liters/h 0.7 0.7
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Cool A 3.4
_
3.1 3.4
_
3.1
Rated current Heat A 4.2
_
3.9 4.2
_
3.9
Cool W 730 730
Rated input Heat W 910 910
Cool % 98
_
98 98
_
98
Power factor Heat % 98
_
97 98
_
97
Type Hermetically sealed rotary type
Compressor Model HV166A1-S10DK 44A072QV2JD
Oil charge 455cc (SUNISO 4GSD) 280cc (SUNISO 4GSD-T)
Evaporator Louver Fin and Grooved tube type
Refrigerant system Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant volume 760g 760g
De-lce system Micro computer controled reversed systems
Noise level
High dB(A) 33 43 33 43
(at cooling)
Med. dB(A) 29 – 29 –
Low dB(A) 27 – 27 –
Fan system
Drive Direct drive
Air flow quantity High m
3
/min. 7.5 28 7.5 28
(at cooling) Med. m
3
/min. 6.8 – 6.8 –
Low m
3
/min. 6.0 – 5.5 –
Fan Cross flow fan Propeller fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4"
Drain piping mm O.D ø 18
Others
Compressor: Thermal protector
Safety device Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Width mm 815 780 815 780
Net dimensions Height mm 278 540 278 540
Depth mm 198 269 198 269
Net weight kg 9 35 9 36
Note: The condition of star " " marked item are ‘ISO5151’ : 1994(E), condition T1.
