Sharp AH-X108E - External Dimensions; Indoor Unit Dimensions; Outdoor Unit Dimensions

AH/AU-X108E
AY/AE-X108E
AH/AU-X138E
AY/AE-X138E
4
Figure E-1. INDOOR UNIT
Figure E-2. OUTDOOR UNIT
790 188
270
800
58
18
19.5
182
Length unit (mm)
EXTERNAL DIMENSIONS
250
280
304
525
10.5
38
58
5
76.5
141.5
515
530
15
728
98 60
59.5
69.5
Length unit (mm)
