EN-6
Using the 3D Glasses
Disposal of the 3D glasses
(Excluding Australia)
Remove the 3D glasses battery, and then follow these
steps to take the 3D glasses apart.
1 Pull out the nose pad with your fingers.
2 Remove the five screws with a Phillips screwdriver
(commercially available).
3 Pull the front casing outward with your fingers
while pulling the base of the right temple arm
inward with your fingers (
s ).
1 Front casing
2 Base
3 Right temple arm
4 Cut off the three cables of the rechargeable
battery unit one by one with a pair of scissors.
• There is the rechargeable battery unit inside 2 on
the right temple arm shown below.
• Insulate the tip of the removed rechargeable
battery cable with material such as scotch tape.
1 Right temple arm
2 Rechargeable battery unit
3 Rear casing
5 Pull out the entire rechargeable battery unit and
remove it from the rear casing.
NOTE
• Used batteries should be disposed in accordance with
local laws and regulations.
