Model
Item
4T-C50AH1X
LCD panel 126 cm
Resolution
8,294,400 pixels (3840
g
2160)
Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV function TV-
standard
Analogue
PAL: B/G, D/K, I SECAM: B/G, D/K, K/K1 NTSC: M
Digital DVB-T / DVB-T2
Receiving
channel
VHF/UHF
44.25—863.25 MHz
CATV S1—S41 ch (including Hyperband)
TV-tuning system
Auto Preset 99 ch
STEREO/BILINGUAL
NICAM: B/G, I, D/K A2 stereo: B/G MTS: M
Audio amplifi er
10 W
g
2
Terminals
ANT (Antenna input)
UHF/VHF 75
q
DIN type
SERVICE ONLY
3.5 mm jack
INPUT 1 (ARC) HDMI
HDMI (HDMI input), ARC
INPUT 2 HDMI HDMI (HDMI input)
INPUT 3 AUDIO in, VIDEO in
AUDIO OUT
AUDIO out, Headphone (
3.5 mm stereo)
USB USB (DC5V 1.5A output)
ETHERNET
(10/100 BASE-T)
Network connector
OSD language
English/Simplifi ed Chinese/Arabic/French/Portuguese/Russian/
Persian/Thai/Vietnamese/Indonesia/Hebrew/Hindi/Malay
Power requirement
AC 110 — 240 V, 50/60 Hz
Power consumption 140 W (0.5 W Standby)
Dimensions
without stand
1122 (W)
g
666 (H)
g
74 (D) mm
with stand
1122 (W)
g
708 (H)
g
253 (D) mm
Weight without stand (with stand) 12.0 kg (12.5 kg)
Operating temperature
0°C to +40°C
•
As a part of policy of continuous improvement, SHARP reserves the right to make design and specifi cation changes
for product improvement without prior notice. The performance specifi cation fi gures indicated are nominal values of
production units. There may be some deviations from these values in individual units.
•
Specifi cation may differ depending on the selected country.
CAUTION
•
Installing the Liquid Crystal Television requires special skill that should only be performed by qualifi ed service
personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.
•
Carefully read the instructions that come with the bracket before beginning work.
Viewing E-Manual
Viewing the Built-in Operation Manual
Displays the built-in operation manual on the screen. You
can read information about how to use this device.
1 Press (HOME) to display the HOME screen, and
then press / to select “Settings”.
Press
, press / to select “Manual”, and then
press ENTER.
This displays the built-in operation manual screen.
2 When you select contents, its page will be displayed.
1
2
Appendix
Troubleshooting
The problems described below are not always caused by malfunctions. Check the TV again before having the TV serviced.
Problem Possible Solution
•
No power.
•
Check if you pressed
POWER
on the remote control unit.
•
Is the AC cord disconnected?
•
Has the power been turned on?
•
Remote control unit does
not operate.
•
Are batteries inserted with polarity (+, –) aligned?
•
No picture.
•
Is connection to other components correct?
•
No sound.
•
Is connection to other components correct?
CLEARING THE PASSWORD
If you forget the password, clear the password using the following procedure.
1 From the HOME screen, select “Settings” > “Menu”, and then press / to select “Initial setup”.
2 Press / to select “Child lock”, and then press ENTER and the password input screen display.
3 If you enter “3001” using 0 – 9, the “Child lock” setting menu will be displayed.
4 Press / to select “Set password”, and then press ENTER to set the password.
5 Enter the 4-digit number as a password using 0 – 9, and then enter the same 4-digit to confi rm. The new password
is now set.
Specifi cations
