Unit : mm
Dimensional Drawing (Continued)
119
400 582582
200 580
79
5
Screw size for wall mount M8
VESA SPEC
200 x 400
UPPER VESA SCREW DEPTH
A B
17
17
13
UPPER/LOWER VESA SCREW TYPE
M8
LOWER VESA-A SCREW DEPTH
LOWER VESA-B SCREW DEPTH
200195 388
Dimensional Drawing
1358
83
56
1333
799
864
752
1115
124
300
300529 529
300529 529
VESA SPEC
200 x 300
UPPER/LOWER VESA SCREW DEPTH
30
UPPER/LOWER VESA SCREW TYPE
M6
VESA SPEC
200 x 300
UPPER/LOWER VESA SCREW DEPTH
30
UPPER/LOWER VESA SCREW TYPE
M6
Unit : mm
4T-C60DK1X
Unit : mm
4T-C60DL1X
200195 388
1358
1333
1202
83
56
152
379
860
752
799
16
61
16
65
