51
Appendix
Removing speakers
1
2
3
Remove the terminal cover.
Perform the same steps for both sides.
Unfasten the screws.
Perform the same steps for both sides.
Unplug the speaker cable.
Perform the same steps for both sides.
CAUTION
• Do not remove the stand and speaker from the TV unless using an optional bracket to mount it.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
NOTE
• To attach the speakers, perform the steps in reverse order.
4
Lift, then remove the speaker box from the TV.
