3
Preparation
Setting the TV
Bundling the cables
NOTE
• The illustration shows the LC-32GA6E.
To TV antenna terminal
To FM antenna terminal
Standard DIN45325 plug
(IEC 169-2)
75-ohm coaxial cable
FM antenna cable
Removing the terminal cover
Press the two hooks and slide the cover toward
the left of TV to remove.
TV (Rear view)
AC cord
Product shape varies
in some countries.
Cable clamp
Cable tie
