Sharp Aquos LC 37D64U

9
Part Names
TV (Front)
OPC indicator
(See page 19.)
POWER indicator
(See page 12.)
OPC sensor
(See page 19.)
Remote control sensor
SLEEP indicator
(See page 13.)
TV (Top/Side/Rear)
RS-232C terminal
DIGITAL AUDIO OUTPUT
terminal
INPUT 4 terminal (HDMI)
INPUT 5 terminals (HDMI)
INPUT 6 terminals (PC-IN)
Antenna/Cable in
INPUT 1 terminals
AC INPUT terminal
INPUT 2 terminals
AUDIO OUTPUT terminals
SERVICE
terminal
INPUT 3
terminals
POWER button
INPUT button
MENU button
Channel buttons
(CHV/U)
Volume buttons
(VOL
l
/
k
)
