Sharp Aquos LC-40LE530X

25
PC compatibility chart
Resolution
Horizontal
Frequency
Vertical
Frequency
VESA
Standard
Analogue
(D-Sub)
Digital (HDMI)
VGA
720 g 400
31.5 kHz 70 Hz
✔✔
640 g 480
31.5 kHz 60 Hz
✔✔✔
SVGA
800 g 600
37.9 kHz 60 Hz
✔✔✔
XGA
1,024 g 768
48.4 kHz 60 Hz
✔✔✔
WXGA
1,360 g 768
47.7 kHz 60 Hz
✔✔✔
SXGA
1,280 g 1,024
64.0 kHz 60 Hz
✔✔✔
SXGA+
1,400 g 1,050
65.3 kHz 60 Hz
✔✔✔
DDC is a registered trademark of Video Electronics Standards Association.
Power Management is a registered trademark of Sun Microsystems, Inc.
VGA and XGA are registered trademarks of International Business Machines Corp.
RS-232C commands list
Commands
• Commands not indicated here are not guaranteed to operate.
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POWER SETTING
P O W R 0 _ _ _ POWER OFF (STANDBY)
INPUT
SELECTION A
ITGD____
INPUT SWITCHING (TOGGLE)
I T V D _ _ _ _ ATV (CHANNEL FIXED)
I D T V _ _ _ _ DTV (CHANNEL FIXED)
IAVD*___
INPUT 1f7 (1f7)
CHANNEL
DCCH * * _ _
ATV DIRECT CHANNEL
(1f99)
C H U P _ _ _ _ ATV CHANNEL UP
C H D W _ _ _ _ ATV CHANNEL DOWN
DTVD* * * _
DTV DIRECT CHANNEL
(1f999)
D T U P _ _ _ _ DTV CHANNEL UP
D T D W _ _ _ _ DTV CHANNEL DOWN
AV MODE
SELECTION
A V M D 0 _ _ _ TOGGLE
A V M D 1 _ _ _ STANDARD
A V M D 2 _ _ _ MOVIE
A V M D 3 _ _ _ GAME
A V M D 4 _ _ _ USER
A V M D 5 _ _ _ DYNAMIC (FIXED)
A V M D 6 _ _ _ DYNAMIC
AVMD7_ __PC
NOTE
• If an underbar (_) appears in the parameter column, enter a
space.
• If an asterisk (*) appears, enter a value in the range indicated
in brackets under CONTROL CONTENTS.
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
VOLUME V O L M * * _ _ VOLUME (0-60)
POSITION
HPOS * * * _
H-POSITION (AV) (–10f010)
HPOS * * * _
H-POSITION (PC) (000f180)
VPOS * * * _
V-POSITION (AV) (–20f020)
VPOS * * * _
V-POSITION (PC) (000f120)
CLCK * * * _
CLOCK (000f180)
PHSE * * * _
PHASE (000f015)
WIDE MODE
W I D E 0 _ _ _ TOGGLE (AV)
W I D E 1 _ _ _ NORMAL (AV)
W I D E 2 _ _ _ ZOOM 14:9 (AV)
W I D E 3 _ _ _ PANORAMA (AV)
W I D E 4 _ _ _ FULL (AV)
W I D E 5 _ _ _ CINEMA 16:9 (AV)
W I D E 6 _ _ _ CINEMA 14:9 (AV)
W I D E 7 _ _ _ NORMAL (PC)
W I D E 9 _ _ _ FULL (PC)
W I D E 1 0 _ _ DOT BY DOT (AV/PC)
W I D E 1 1 _ _ UNDERSCAN (AV)
MUTE
M U T E 0 _ _ _ TOGGLE
M U T E 1 _ _ _ MUTE ON
M U T E 2 _ _ _ MUTE OFF
SRS TS HD
A C S U 0 _ _ _ SRS TS HD TOGGLE
A C S U 1 _ _ _ SRS TS HD ON
A C S U 2 _ _ _ SRS TS HD OFF
AUDIO CHANGE A C H A _ _ _ _ TOGGLE
SLEEP TIMER
O F T M 0 _ _ _ OFF
O F T M 1 _ _ _ SLEEP TIMER 30 MIN
O F T M 2 _ _ _ SLEEP TIMER 1 HOUR
OFTM3 _ _ _
SLEEP TIMER 1 HOUR
30 MIN
O F T M 4 _ _ _ SLEEP TIMER 2 HOUR
OFTM5 _ _ _
SLEEP TIMER 2 HOUR
30 MIN
TEXT
T E X T 0 _ _ _ TEXT OFF
T E X T 1 _ _ _ TEXT CHANGE TOGGLE
DCPG * * * _
DIRECT PAGE JUMP
(100f899)
