• The TV can be controlled from a PC, control panels and other devices using the RS-232C or IP.
• Use a cross-type RS-232C cable, ETHERNET cable (commercially available) or wireless LAN for
the connections.
• This operation system should be used by a person who is accustomed to using computers.
Set this function when operating the TV from equipment connected by LAN or wireless LAN. To
perform the operation, refer to "Smart TV".
Remote Control App
When "Remote Control App" is selected, "Change" will be highlighted. Press ENTER.
Detailed Settings
Make the detailed settings (Login ID, password, etc.).
Follow the on-screen instructions to configure the settings.
Set the name of the TV displayed on other network devices.
• Use the software keyboard to set the name.
See Daae 9-5 for details on the software keyboard.
Connect to the TV with the following settings made for IP on the PC.
IP protocol: TCP/IP
Host IP address: Set the IP address on the TV menu
Service: None (Do net select Telnet or SSH)
TCP port#: Set a port number on the TV menu (Control
port)
When you set your ID and password on the TV menu, you need to enter them as soon as you
connect to the TV.
• When you use this function, make settings for "AQUOS Remote Control".
• The connection will be cut off when there has been no communication for 3 minutes.
Baud rate:
Data length:
Parity bit:
Stop bit:
Flow control:
Communication procedure
Set the RS-232C communication settings on the PC to match the TV's communication conditions.
The TV's communication settings are as follows:
9,600 bps
8 bits
None
1 bit
None
Send the control commands from the PC via the RS-232C or IP.
The TV operates according to the received command and sends a response message to the PC.
Do not send multiple commands at the same time.
Wait until the PC receives the OK response before sending the next command.
ENG 8-3
