Sharp AU-MP14 - Electrical Parts

CHAPTER 2. ELECTRIC CIRCUIT
[1] ELECTRIC PARTS
1. AH-129 / AU-129
DESCRIPTION
MODEL
REMARKS
SITE
Compressor
RH207VXGT 220V, 50Hz, 1120W
OUTDOOR
Indoor fan motor CMOT-A448JBKZ 220 - 240V , 50Hz INDOOR
Outdoor fan motor
CMOTLB182JBEZ 220 - 240V , 50/60Hz
OUTDOOR
Indoor fan motor capacitor
— 450V, 2
µF INDOOR
Outdoor fan motor capacitor
— 400V, 2
µF
OUTDOOR
Running capacitor
— 400V, 30µF
OUTDOOR
Transformer — Primary ; AC 220 / 240V 50Hz
Secondary ; AC15.3V , 50Hz
INDOOR
—
Fuse — 250V, 2.5A INDOOR
2. AH-MP14 / AU-MP14
6
DESCRIPTION
MODEL
REMARKS
SITE
Compressor
RH207VXGT 220V, 50Hz, 1120W
OUTDOOR
Indoor fan motor CMOT-A448JBKZ 220 - 240V , 50Hz INDOOR
Outdoor fan motor
CMOTLB182JBEZ 220 - 240V , 50/60Hz
OUTDOOR
Indoor fan motor capacitor
— 450V, 2
µF INDOOR
Outdoor fan motor capacitor
— 400V, 2
µF
OUTDOOR
Running capacitor
— 400V, 30µF
OUTDOOR
Transformer — Primary ; AC 220 / 240V 50Hz
Secondary ; AC15.3V , 50Hz
INDOOR
—
Fuse
— 250V, 2.5A INDOOR
