Sharp AU-X18 Series - Part Names (Unit

EN-2
INDOOR UNIT
1
Inlet(Air)
2
OpenPanel
3
AirFilter
4
ReceiverWindow
5
VerticalAirowLouver
6
HorizontalAirowLouver
7
Outlet(Air)
8
OPERATIONLamp(green )
9
TIMERLamp(orange )
10
ERRORLamp
(ForAH-X10/13/15/18/20series:green,
ForAH-X24/25series:blue)
PART NAMES (UNIT)
Indoorunitapperancemaybedifferentfromtheimageabove.
※
1
2
3
4
5
6
7
8
9
10
(ForAH-X10series)
(ForAH-X24/25series)
(ForAH-X13/15/18/20series)
ThepositionofON/OFFbutton:
B129_EN.indd 2 2021/11/10 14:27:21
