REPLACEMENT PARTS LIST [AU-A07BE/A07BE-C]
CABINET AND UNIT PARTS
1- 1 LBSHCA022JBF0 Bushing 1 AE
1- 2 CMOTLA592JBE0 Fan motor 1 BP
1- 3 NFANPA020JBEA Propeller fan 1 AW
1- 4 PANGKA044JBY0 Motor angle ssembly 1 AK
1- 5 PSKR-A094JBP0 Bulkhead [AU-A07BE] 1 AG
1- 5 PSKR-A106JBP0 Bulkhead [AU-A07BE-C] 1 AM
1- 6 GPLTPA014JBFA Left side cover 1 AR
1- 7 CFTA-A266JBKZ Terminal cover ass'y [AU-A07BE] 1 AU
1- 7 CFTA-A276JBKZ Terminal cover ass'y [AU-A07BE-C] 1 AU
1- 8 PBOX-A351JBWZ Control box 1 AK
1- 9 GCAB-A105JBTA Cabinet 1 BA
1-10 GGADFA030JBEA Fan guard 1 AY
1-11 PSEL-C147JBEZ Seal 1 AC
1-12 PSPF-A777JBEZ Compressor cover [AU-A07BE] 1 AT
1-12 PSPF-A695JBE0 Compressor cover [AU-A07BE-C] 1 AZ
1-13 PSEL-A345JBE0 Cabinet seal 1 AK
1-14 TSPC-D665JBRZ Name label [AU-A07BE] 1 AG
1-14 TSPC-E042JBRZ Name label [AU-A07BE-C] 1 AF
1-15 TLABBA029JBRA SHARP badge 1 AD
1-16 CCHS-A751JBTA Base pan assembly [AU-A07BE] 1 BC
1-16 CCHS-A636JBTA Base pan assembly [AU-A07BE-C] 1 BF
1-17 PSPF-A277JBE0 Angle seal 1 AK
1-18 PSEL-A347JBE0 Angle seal 2 AK
1-19 PSEL-A344JBE0 Consensor seal 2 AK
1-20 CPLT-A058JBKZ Side cover ass'y 1 AW
1-21 GPLTMA058JBTA Side cover R 1 AU
1-22 PSEL-C141JBEZ Insulator 1 AU
1-23 PSEL-C142JBEZ Insulator 1 AU
1-24 PSEL-C144JBEZ Insulator 1 AD
1-25 PSEL-C071JBEZ Aluminum tape 1 AC
1-26 TLABCB412JBRZ Wiring diagram [AU-A07BE] 1 AC
1-26 TLABCB573JBRZ Wiring diagram [AU-A07BE-C] 1 AF
1-27 PSEL-C152JBEZ Insulator 1 AE
1-28 PSEL-C145JBEZ Insulator 1 AC
CONTROL BOX PARTS
2- 1 RHOG-A186JBZZ Protector [AU-A07BE] 1 AT
2- 2 LBNDKA062JBW0 Capacitor clamp 1 AD
2- 3 QW-IZA014JBZZ Compressor cord [AU-A07BE] 1 AN
2- 3 QW-IZA028JBZZ Compressor cord [AU-A07BE-C] 1 AP
2- 4 RC-HZA316JBE0 Running capacitor [AU-A07BE] 1 AY
2- 4 RC-HZA301JBE0 Running capacitor [AU-A07BE-C] 1 AX
2- 5 RC-HZA419JBZZ Fan motor capacitor 1 AP
2- 6 QTANZA002JBZZ Terminal board 1 AN
2- 7 LHLD-0261JBM0 Cord holder 1 AB
CYCLE PARTS
3- 1 FCMPRA106JBKZ Compressor ass'y(Including for Ref.No.2-1)[AU-A07BE] 1 CC
3- 1 FCMPRA129JBKZ Compressor ass'y 1 CC
3- 1-1 PCMPRA334JBEZ Compressor [AU-A07BE] 1 CB
3- 1-1 PCMPRA369JBEZ Compressor [AU-A07BE-C] 1 CB
3- 1-2 PSEL-B379JBE0 Terminal gasket [AU-A07BE] 1 AN
3- 1-2 PSEL-B172JBE0 Terminal gasket [AU-A07BE-C] 1 AD
3- 1-3 PSEL-B380JBE0 Gasket washer [AU-A07BE] 1 AG
3- 1-3 PSEL-B722JBE0 Gasket washer [AU-A07BE-C] 1 AE
3- 1-4 PCOV-A628JBEZ Terminal cover [AU-A07BE] 1 AK
3- 1-4 PCOV-A378JBEZ Terminal cover [AU-A07BE-C] 1 AH
3- 1-5 GLEG-A097JBE0 Compressor cushion [AU-A07BE] 3 AF
3- 1-5 GLEG-A085JBE0 Compressor cushion [AU-A07BE-C] 3 AK
3- 1-6 LX-NZA164JBE0 Special nut [AU-A07BE] 1 AE
3- 1-6 LX-NZA152JBE0 Special nut [AU-A07BE-C] 1 AD
3- 2 PCON-A458JBPZ Condenser [AU-A07BE] 1 BS
3- 2 PCON-A477JBPZ Condenser [AU-A07BE-C] 1 BS
3- 3 DVLV-A189JBK0 2 Way valve unit 1 BA
3- 4 PSEN-A004JBK0 Flare nut ass'y 1/4" 1 AE
3- 5 LX-NZA081JBE0 Valve cap 2 AG
3- 6 PGUMSA205JBE0 Damper rubber 1 AC
3- 7 DVLV-A212JBK0 3 way valve unit 1 BB
3- 8 PSEN-A005JBK0 Flare nut assembly 3/8" 1 AG
3- 9 LX-NZA034JBE0 Service cap 1 AD
3-10 PCPY-A777JBPZ Capillary tube 1 AG
3-11 PGUMS0147JBE0 Damper rubber 1 AE
3-12 LX-NZA026JBE0 Special nut 3 AC
3-13 PGUM-0034JBE0 Damper rubber [AU-A07BE-C] 2 AF
REF. NO. PART NO. DESCRIPTION Q'TY CODE
