HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
REF. NO. PART NO. DESCRIPTION Q'TY CODE
3-14 LBND-A046JBE0 Wire fixing band [AU-A07BE-C] 2 AE
SCREWS, NUT AND WASHER
4- 1 LX-WZA019JBE0 Special washer 1 AD
4- 2 LX-BZA078JBE0 Special screw 4 AB
4- 3 LX-BZA075JBE0 Special screw 1 AA
4- 4 LX-WZA019JBE0 Special washer 1 AB
4- 5 LX-NZA030JBE0 Special nut 1 AB
4- 6 LX-CZA038WRE0 Special screw 2 AA
4- 7 LX-BZA076JBE0 Special screw 6 AA
4- 8 XCPSD40P20000 Tapping screw 1 AA
PACKING PARTS
5- 1 CPADBA231YDK0 Bottom pad ass'y 1 AP
5- 2 SPAKCA713JBEZ Packing case [AU-A07BE] 1 AX
5- 2 SPAKCA969JBEZ Packing case [AU-A07BE-C] 1 AW
