REMOTE CONTROL
1 TRANSMITTER
2 DISPLAY (Liquid Crystal Display)
3 ON/OFF Button
4 TEMP. Button
5 DISPLAY Button
6 PLASMACLUSTER Button
7 ONE-HOUR OFF TIMER Button
8 MODE Button
9 TIMER ON Button (for setting the timer)
0 FAN Button
q TIMER OFF Button (for setting the timer)
w SWING Button
e TIMER CANCEL Button
r TURBO Button
t RESET Button
y MODE SYMBOLS
: AUTO : HEAT
: COOL : DRY
u TURBO SYMBOL
i PLASMACLUSTER SYMBOL
o FAN SPEED SYMBOLS
: AUTO : Manual setting
p TEMPERATURE AND TIMER COUNT DOWN
INDICATOR
a TRANSMITTING SYMBOL
s TIMER ON/TIMER OFF INDICATOR
Indicates when timer on or timer off is set.
L.C.D. REMOTE CONTROL DISPLAY
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
i
o
p
a
s
PART NAMES
E-6
