PART NAMES
1 Inlet (Air)
2 Open Panel
3 AUX. Button
4 Air Filters
5 Receiver Window
6 Louvre Unit
Open to clean the inside of the air
conditioner.
7 Power Supply Cord
(AY-AP18CJ only)
8 Indicator Panel
9 Vertical Adjustment Louvres
0 Horizontal Adjustment Louvres
q Outlet (Air)
w Remote Control
e AUTO FAN SPEED Lamp (green )
r FAN SPEED Lamp (green )
t PLASMACLUSTER Lamp
(blue, green)
y TIMER Lamp (orange )
u OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
