AYAP7FHR
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[5] OUTDOOR UNIT PARTS
1-1 GCAB-A210JBTA AS Top table
1-2 TLABCC055JBRZ AF Wiring diagram[AEA7FHR]
1-2 TLABCC074JBRZ AF Wiring diagram[AEA9FHR]
1-3 CCOV-A130JBKZ AM Cover ass'y
1-4 CCHS-A919JBYA BK Base pan ass'y
1-5 LANGKA124JBPZ AR Fan motor angle
1-7 CFTA-A337JBKZ BC Side cover ass'y
1-8 CMOTLB181JBEZ BH Fan motor
1-9 PSEL-C834JBEZ AK Seal
1-10 PSEL-C 895JBEZ AF Bulkhead seal C
1-11 PSKR-A288JBPZ AX Bulkhead
1-12 GCAB-A282JBTA BC Front panel
1-13 GGADPA004JBFA AR Fan guard
1-14 JHNDPA011JBFA AS Holder
1-15 LHLD-A573JBFA AC Cord clamp
1-16 LPLTPA026JBFA AC Cord clamp plate
1-17 NFANPA101JBEZ AR Propeller fan
1-18 PPLT-A385JBTA AU Side cover L
1-19 PPLT-A421JBTZ AX Side cover R[AEA9FHR]
1-19 PPLT-A392JBTA AV Side cover R[AEA7FHR]
1-20 PSEL-C 837JBEZ AE Condenser seal[AEA7FHR]
1-20 PSEL-C 850JBEZ AF Condensor seal[AEA9FHR]
1-21 PSEL-C 838JBEZ AC F-panel seal
1-22 PSEL-C 839JBEZ AC Insulator
1-23 PSEL-C 867JBEZ AF Seal[AEA7FHR]
1-23 PSEL-C 835JBEZ AC Seal[AEA9FHR]
1-24 PSEL-C 870JBEZ AD Seal
1-25 PSEL-C 871JBEZ AD Seal
1-27 PSPF-A941JBEZ AV Compressor cover[AEA7FHR]
1-27 PSPF-A946JBEZ AV Compressor cover[AEA9FHR]
1-28 TLABBA149JBRZ AG Sharp badge
1-29 TSPC -F03 8JB R Z AK Name badge[AEA7FHR]
1-29 TSPC -F05 7JB R Z AK Name badge[AEA9FHR]
2-1 LBNDKA062JBW0 AD
Capacitor clamp
2-2 PBOX-A447JBPZ AR Control box
2-3 QTANZA027JBZZ AQ Terminal board
2-4 QW-IZA082JBZZ AP Comp wiring[AEA7FHR]
2-4 QW-IZA089JBZZ AN Comp wiring[AEA9FHR]
2-5 QW-VZE889JBZZ AF Lead wire
2-6 QW-VZE890JBZZ AF Lead wire
2-7 RC-HZA517JBZZ AX Running capacitor[AEA7FHR]
2-7 RC-HZA516JBZZ AZ Running capacitor[AEA9FHR]
2-8 RC-HZA513JBZZ AR Fan motor capacitor
3-1 CVLV-A764JBKZ BP Reverse valve ass'y[AEA7FHR]
3-1 CVLV-A767JBKZ BP Reverse valve ass'y[AEA9FHR]
3-1-1 CCIL-A122JBEZ AU Coil
3-1-2 LX-BZA26 8JBEZ AB Special screw
3-1-3 PVLVXA052JBEZ BB Reverse valve
3-2 CCPY-A189JBKZ BB Cappilary ass'y[AEA7FHR]
3-2 CCPY-A190JBKZ BB Capillary ass'y[AEA9FHR]
3-3 DVLV-A530JBKZ AT 2way valve unit
3-4 DVLV-A529JBKZ AW 3way valve unit
3-5 GLEG-A123JBEZ AN Compressor cushion[AEA7FHR]
3-5 GLEG-A103JBE0 AG Compressor cushion[AEA9FHR]
3-6 LX-NZA002JBE0 AA Special nut[AEA7FHR]
3-6 LX-NZA148JBE0 AD Frange nut[AEA9FHR]
3-7 PCMPRA472JBEZ CD Compressor[AEA7FHR]
3-7 PCMPRA473JBEZ CB Compressor[AEA9FHR]
3-8 PCOV-A002JBE0 AE Terminal cover[AEA7FHR]
3-8 PCOV-A371JBE0 AF Terminal cover[AEA9FHR]
3-9 PSEL-A006JBE0 AC Terminal gasket[AEA7FHR]
3-9 PSEL-B160JBE0 AH Terminal gasket[AEA9FHR]
3-10 PSEL-B 161JBE0 AH Gasket washer[AEA9FHR]
3-11 RHOG-A236JBZZ AZ Overload relay[AEA7FHR]
3-11 RHOG-A237JBZZ AV Overload relay[AEA9FHR]
3-12 MSPR-A005JBE0 AB Protector spring[AEA7FHR]
3-12 MSPR-A114JBE0 AF Protector spring[AEA9FHR]
3-13
DCON-A284JBPZ BU Condenser[AEA7FHR]
3-13 DCON-A28 8JBPZ CA Condenser[AEA9FHR]
3-14 PSEN-A044JBKZ AG Flare nut ass'y
3-15 PSEN-A045JBKZ AK Flare nut ass'y
4-1 LX-BZA351JBEZ AD Special screw
4-2 LX-BZA355JBEZ AE Special screw
4-3 LX-NZA313JBEZ AE Special nut
4-4 LX-BZA075JBE0 AA Special screw
4-5 LX-BZA353JBEZ AD Tapping screw
4-6 LX-BZA364JBEZ AC Special screw
4-7 LX-NZA326JBEZ AA Special nut
