AH-X079E/X099E
AU-X079E/X099E
41
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2-27 RH-VZA037JBE0 Varistor (NR1) 1 AE
2-28 RIC--A025BDE0 IC (IC2) 1 AE
2-29 RLMP-A043JBE0 LED (LED102) 1 AC
2-30 RRLYJA067JBE0 Relay (RY1) 1 AP
2-31 RTRNPA001JBE0 Transformer 1 AS
2-32 VHPLT3P8A//-3 LED (LED101) 1 AG
2-33 VHRPC817X7/1B Photo coupler (PC1) 1 AD
2-34 VHRPC853H//-6 Photo coupler (PC2) 1 AG
2-35 VHRS201D01/-6 Solid state relay (SSR1) 1 AK
2-36 RD-TZA007BDE0 Diode (D6, D7) 2 AB
2-37 RH-DZA106JBE0 Diode (D1, D2, D3, D4) 4 AB
2-38 VHD1SS270A/-1 Diode (D5) 1 AA
2-39 VHEHZ24-2//-1 Zenner diode (ZD2) 1 AB
2-40 VHEHZ5C-1//-1 Zenner diode (ZD1) 1 AB
CYCLE PARTS
3- 1 CPIPCA473JBK0 Pipe assembly 1 BA
3- 2 PSEN-A004JBK0 Flare nut assembly (1/4") 1 AE
3- 3 PSEN-A005JBK0 Flare nut assembly (3/8") 1 AG
3- 4 PVLV-0341JBE0 Flare union (1/4") 1 AG
3- 5 PVLV-0342JBE0 Flare union (3/8") 1 AH
3- 6 DEVA-A022JBK0 Evaporator assembly [AH-X079E/AY-X079E] 1 BK
3- 6 DEVA-A086JBK0 Evaporator assembly [AH-X099E/AY-X099E] 1 BS
ACCESSORY PARTS
4- 1 CRMC-A447JBE0 Remote controller [AH-X079E/X099E] 1 BB
4- 1 CRMC-A442JBE0 Remote controller [AY-X079E/X099E] 1 BB
4- 2 FCOV-A013JBFS Screw cover 2 AC
4- 3 LX-NZ0247JBE0 Special nut 1 AB
4- 4 XTTSD40P20000 Tapping screw (for fixing the cord holder) 1 AA
4- 5 LX-NZ0247JBE0 Special nut (for fixing long screw steadily) 7 AB
4- 6 LPFT-A029JBF0 Drain hose adpter [AY-X079E/X099E] 1 AD
4- 7 PPLTNA043JBW0 Mounting plate 1 AR
4- 8 XTTSD45P30000 Long screw 6 AA
4- 9 TINSEA217JBR0 Operation manual 1 AD
4-10 TINS-A550JBR0 Installation manual 1 AE
4-11 TINS-A551JBR0 Installation manual 1 AE
4-12 LX-BZA106JBE0 Special screw (for hanging remote controller) 1 AE
4-13 LHLD-A281JBFA Cord holder
(for covering the terminal board of indoor unit) 1 AC
4-14 UBATUA025JBE0 Battery pack 1 AE
SCREWS
5- 1 LX-BZA075JBE0 Special screw 1 AA
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
