Sharp AY-X127E - External Dimensions

AH-X127E
AU-X127E
AY-X127E
AE-X127E
4
EXTERNAL DIMENSIONS
Figure E-1. INDOOR UNIT
Figure E-2. OUTDOOR UNIT
790 188
270
800
58
18
19.5
182
Length unit (mm)
250
280
304
525
10.5
38
58
5
76.5
141.5
515
530
15
728
98 60
59.5
69.5
Length unit (mm)
