4
AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
Figure E-3. INSTALLATION DIMENSIONS
815 (unit size)
More than 50mm
E
Center of wall hole:
Leftward piping
Center of wall hole: Backward piping
Outline of indoor unit
55
95
80
55
AJ
IF
E
D
D
FA
C
J
H
I
GB
21
278 (unit size)
38
Ceiling
E
3
5
Table of Contents
Table of Contents
1
Specifications
2
External Dimensions
3
Wiring Diagrams
5
Electrical Parts
9
Block Diagram
10
Microcomputer Control System
12
Functions
17
Tips about Indicator Panel
21
Self Clean Operation
22
Function and Operation of Protective Procedures
27
Breakdown Diagnosis Procedure
29
Refrigeration Cycle
32
Performance Curves
33
Disassembling Procedure
34
Option
41
Replacement Parts List
43
