46
AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
REPLACEMENT PARTS LIST [AE-X08BE-C/10BE-C/13BE]
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CONTROL BOX PARTS
1- 1 CMOTLA902JBEZ Fan motor [AE-X08BE-C/X10BE-C] 1 BK
1- 1 CMOTLA903JBEZ Fan motor [AE-X13BE] 1 BL
1- 2 RTRN-A256JBE0 Current transfoemer CT1 1 AG
1- 3a RFIL-A104JBZZ Common coil [AE-X08BE-C/X10BE-C] 1 AR
1- 3b RFIL-A105JBZZ Common coil [AE-X08BE-C/X10BE-C/X13BE] 1 AR
1- 3c RFIL-A106JBZZ Common coil [AE-X13BE] 1 AV
1- 4 DPWBFA282JBKZ Electric control board [AE-X08BE-C/X10BE-C] 1 BP
1- 4 DPWBFA240JBKZ Electric control board [AE-X13BE] 1 BQ
1- 5 QTANZA001JBZZ Terminal board (4P) 1 AQ
1- 6 RIC—A022BDE0 Integrated circuit IC2 [AE-X08BE-C/X10BE-C] 1 AE
1- 6 VHIK7818API-1 Integrated circuit IC2 [AE-X13BE] 1 AF
1- 7 VSKRC245M//-3 Transistor Q3 1 AC
1- 8 VHRPC817X7/1B Photo coupler PC1 1 AE
1- 8 VHRPC817X7/1B Photo coupler PC1,PC3, PC4 [AE-X13BE] 3 AE
1- 9 VHRPC853H//-6 Photo coupler PC2 1 AG
1-10 RC-AZA046JBE0 Capacitor [AE-X08BE-C/X10BE-C] 1 BE
1-10 RC-EZA249JBZZ Capacitor [AE-X13BE] 1 BP
1-11 RH-DZA117JBE0 Diode bridge [AE-X08BE-C/X10BE-C] 1 AM
1-11 RH-DZA087JBE0 Diode bridge [AE-X13BE] 1 AQ
1-12 RH-HZ0011JBE0 PTC thermistor 1 AN
1-13 RH-TZA145JBE0 Power transistor module(IPM)[AE-X08BE-C/10BE-C] 1 BU
1-13 VHITM38++++-1 Power transistor module(IPM)[AE-X13BE] 1 BY
1-14 PDAI-A126JBWZ Terminal plate 1 AE
1-15 VHITM-05C//-6 Active filter [AE-X08BE-C/X10BE-C] 1 BP
1-15 RH-TXA003JBZZ Active filter [AE-X13BE] 1 BS
1-16 RTHM-A022JBE0 Compressor thermistor 1 AN
1-17 RH-HXA010JBZZ Thermistor 1 AX
1-18 RTRN-A199JBE0 Choke coil [AE-X08BE-C/X10BE-C] 1 BE
1-18 RTRN-A286JBEZ Choke coil [AE-X13BE] 1 BF
1-19 PBOX-A343JBWZ Control box 1 AR
1-20 LBND-A042JBE0 Wire fixing band 10 AC
1-21 PSPA-A151JBZZ Spacer 5 AE
1-22 LHLD-A479JBFZ Heat sink holder 1 AE
1-23 PRDAFA140JBEZ Heat sink for powertransistor module[AE-X08BE-C/10BE-C] 1 AX
1-23 PRDAFA142JBEZ Heat sink for powertransistor module [AE-X13BE] 1 AX
1-24 QW-VZD962JBZZ Lead wire (CN14-QM1) [AE-X13BE] 1 AE
1-25 PSHE-A190JBEZ Protect sheet 1 AL
1-26 PSEL-C061JBEZ Insulator 1 AE
1-27 PSPA-A144JBE0 Spacer 2 AC
1-28 RFIL-A064JBE0 Ferrite core 5 AF
1-29 QW-VZD961JBZZ Lead wire (CN13-AF1) [AE-X13BE] 1 AG
1-30 QW-VZD871JBZZ Lead wire (L1+, L1-) 2 AG
1-31 QW-VZD857JBZZ Lead wire (Earth) 1 AC
1-32 QW-VZD868JBZZ Lead wire (MRY1 - DB1) 1 AG
1-33 QW-VZD861JBZZ Lead wire (MRY1 - PTC) 1 AF
1-34 QW-VZD958JBZZ Lead wire (DB1+-AF(I+)) 1 AK
1-35 QW-VZD866JBZZ Lead wire (T3 - TB2) 1 AF
1-36 QW-VZD873JBZZ Lead wire (T10 - IPM(-)) 1 AF
1-37 QW-VZD867JBZZ Lead wire (T5 - DB1)) 1 AG
1-38 QW-VZD864JBZZ Lead wire (T2 - TBN) 1 AF
1-39 QW-VZD865JBZZ Lead wire (T1 - TB1) 1 AF
1-40 QW-VZD859JBZZ Lead wire (C8(+) - T7) 1 AE
1-41 QW-VZD870JBZZ Lead wire (C8(+) - AF(0+))[AE-X08BE-C/X10BE-C] 1 AG
1-42 QW-VZD960JBZZ Lead wire (C8-AF) [AE-X13BE] 1 AL
1-43 QW-VZD869JBZZ Lead wire (C8(-) - AF(0-))[AE-X08BE-C/X10BE-C] 1 AF
1-44 QW-VZD860JBZZ Lead wire (C8(-) - T8) 1 AE
1-45 QW-VZD872JBZZ Lead wire (T9 - IPM(+)) 1 AE
1-46 QW-IZA023JBZZ Lead wire (Compressor wire) [AE-X08BE-C] 1 AS
1-46 QW-IZA022JBZZ Lead wire (Compressor wire) [AE-X10BE-C] 1 AM
1-46 QW-IZA019JBZZ Lead wire (Compressor wire) [AE-X13BE] 1 AP
1-47 QW-VZD420JBE0 Lead wire (AF lead wire 4P) 1 AE
1-48 RH-IXA726JBZZ Microcomputer IC1 1 AW
1-49 RH-IZA140JBE0 Integrated circuit IC3 1 AE
1-50 RH-TZA098JBE0 Transistor Q1, Q2 2 AB
1-51 RH-VZA020JBE0 Varistor CNR1, CNR2 2 AB
1-52 RH-VXA002JBZZ Varistor NR1, NR2 2 AD
1-53 RH-VZA042JBE0 Surge absorber SA1 1 AH
1-54 LBNDKA099JBWZ Capacitor clamp 1 AS
1-55 PSEL-C122JBEZ Insulator 1 AC
1-56 PSEL-C123JBEZ Insulator 1 AC
1-57 PSEL-C124JBEZ Insulator 1 AC
