47
AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
CABINET AND UNIT PARTS
2- 1 LANGKA124JBPZ Fan motor angle 1 AR
2- 2 LANGKA127JBPZ Fan motor angle sub [AE-X08BE-C/X10BE-C] 1 AE
2- 2 LANGKA123JBPZ Fan motor angle sub [AE-X13BE] 1 AE
2- 3 GCAB-A196JBTA Rear cabinet 1 BD
2- 4 LHLD-A573JBFA Cord clamp 1 AC
2- 5 PFPFPB911JBEZ Motor angle cushion 1 AC
2- 6 GCAB-A195JBTA Front panel 1 BC
2- 7 GGADFA037JBFA Fan guard 1 AT
2- 8 PSEL-C045JBEZ Motor angle cushion 1 AB
2- 9 PSEL-C048JBEZ F panel insulator 1 AC
2-10 PSEL-C049JBEZ F panel insulator 1 AC
2-11 PSEL-C050JBEZ Bulkhead insulator 1 AG
2-12 TLABBA148JBRA Sharp badge 1 AH
2-13 CCHS-A779JBTA Base pan assembly [AE-X08BE-C] 1 BD
2-13 CCHS-A770JBTA Base pan assembly [AE-X10BE-C] 1 BC
2-13 CCHS-A735JBTA Base pan assembly [AE-X13BE] 1 BD
2-14 PFTA-A092JBFA Side cover 1 AQ
2-15 PCOV-A616JBPZ Protect cover 1 AE
2-16 MSPR-A027JBE0 Thermistor spring [AE-X08BE-C/X10BE-C] 1 AB
2-16 MSPR-A026JBE0 Thermistor spring [AE-X13BE] 1 AB
2-17 MSPR-A046JBE0 Protector spring [AE-X10BE-C/X13BE] 1 AC
2-17 MSPR-A104JBE0 Protector spring [AE-X08BE-C] 1 AQ
2-18 NFANPA094JBEZ Propeller fan 1 AX
2-19 PSKR-A223JBWZ Bulkhead [AE-X08BE-C/X10BE-C] 1 AR
2-19 PSKR-A211JBWZ Bulkhead [AE-X13BE] 1 AQ
2-20 TLABKD002JBRZ Number card [AE-X08BE-C] 1 AC
2-20 TLABKD003JBRZ Number card [AE-X10BE-C] 1 AC
2-20 TLABKC747JBRZ Number card [AE-X13BE] 1 AH
2-21 TSPC-E038JBRZ Name badge [AE-X08BE-C] 1 AD
2-21 TSPC-E039JBRZ Name badge [AE-X10BE-C] 1 AD
2-21 TSPC-D593JBRZ Name badge [AE-X13BE] 1 AE
2-22 PSEL-C051JBEZ Side cover seal 1 AE
2-23 FFTA-A014JBKZ Side cover assembly 1 AT
2-24 TLABCB543JBRZ Wiring diagram [AE-X08BE-C] 1 AE
2-24 TLABCB537JBRZ Wiring diagram [AE-X10BE-C] 1 AE
2-24 TLABCB430JBRZ Wiring diagram [AE-X13BE] 1 AE
2-25 DCAB-A114JBKZ Top cover assembly [AE-X08BE-C] 1 AY
2-25 DCAB-A110JBKZ Top cover assembly [AE-X10BE-C] 1 AY
2-25 DCAB-A104JBKZ Top cover assembly [AE-X13BE] 1 AZ
2-26 PSEL-C060JBEZ Insulator for rear cabinet 1 AB
2-27 GCAB-A197JBTA Top cover 1 AX
2-28 JHNDPA011JBFA Holder 1 AS
2-29 PSEL-C046JBEZ Bulkhead insulator 1 AC
2-30 PSEL-C119JBEZ Box insulator 1 AE
2-31 PSEL-C047JBEZ Box insulator 1 AF
2-32 PSEL-C062JBEZ Box insulator 1 AG
2-33 CHLD-A093JBK0 Holder assembly 1 AL
2-34 PSEL-C121JBEZ Side cover seal 1 AC
2-35 PSEL-C120JBEZ Side cover seal 1 AC
2-36 LPLTPA026JBFA Cord clamp plate 1 AC
CYCLE PARTS
3- 1 CVLV-A621JBKZ Reverse valve assembly [AE-X08BE-C] 1 BP
3- 1 CVLV-A620JBKZ Reverse valve assembly [AE-X10BE-C] 1 BN
3- 1 CVLV-A574JBKZ Reverse valve assembly [AE-X13BE] 1 BW
3- 2 DCPY-A218JBKZ Capillary tube assembly [AE-X08BE-C] 1 BF
3- 2 DCPY-A212JBKZ Capillary tube assembly [AE-X10BE-C] 1 BF
3- 2 DCPY-A217JBKZ Capillary tube assembly [AE-X13BE] 1 BF
3- 3 PCON-A455JBPZ Condensor [AE-X08BE-C/X10BE-C] 1 BT
3- 3 PCON-A445JBPZ Condensor [AE-X13BE] 1 BS
3- 4 DVLV-A520JBKZ 3 way valve unit [AE-X08BE-C/X10BE-C] 1 AW
3- 4 DVLV-A466JBKZ 3 way valve unit [AE-X13BE] 1 BA
3- 5 LX-NZA037JBE0 Service nut [AE-X13BE only] 1 AG
3- 6 LX-BZA268JBEZ Special screw [AE-X08BE-C, AE-X10BE-C] 1 AB
3- 6 LX-BZA060JBE0 Special screw [AE-X13BE] 1 AH
3- 7 DVLV-A521JBKZ 2 way valve unit [AE-X08BE-C/X10BE-C] 1 AT
3- 7 DVLV-A462JBKZ 2 way valve unit [AE-X13BE] 1 AW
3- 8 FCMPRA110JBKZ Compressor ass’y
(Including for Ref.No.3-9,3-11,3-12,2-17)[AE-X08BE-C]
1CE
3- 8 FCMPRA120JBKZ Compressor ass’y
(Including for Ref.No.3-9,3-10,3-11)[AE-X10BE-C]
1CE
3- 8 FCMPRA065JBK0 Compressor ass’y
(Including for Ref.No.3-9,3-10,3-11)[AE-X13BE]
1CM
3- 9 PCMPRA338JBEZ Compressor [AE-X08BE-C] 1 CA
3- 9 PCMPRA350JBEZ Compressor [AE-X10BE-C] 1 CB
3- 9 PCMPRA267JBE0 Compressor [AE-X13BE] 1 CK
3-10 LBSHCA005JBE0 Terminal bushing [AE-X10BE-C/X13BE] 1 AA
3-11 PCOV-0562JBE0 Terminal cover [AE-X10BE-C/X13BE] 1 AD
3-11 PCOV-A321JBE0 Terminal cover [AE-X08BE-C] 1 AR
3-12 PSEL-A971JBE0 Terminal gasket [AE-X08BE-C] 1 AN
REF. NO. PART NO. DESCRIPTION Q'TY CODE
To Next Page
