AYXPC18LR
2 – 6
PFCM P.W.B.
IPM P.W.B
from ELECTROLYTIC CAPACITOR C9 (-)
from ELECTROLYTIC
CAPACITOR C9 (+)
from PFC COIL
from PFC COIL
from CONTROL BOARD
P.W.B. MRY1OUT
from CONTROL BOARD P.W.B. BCN13
from CONTROL BOARD
P.W.B. "T6"
from ELECTROLYTIC CAPACITOR C10(+)
from ELECTROLYTIC
CAPACITOR C10(-)
from COMPRESSOR TERMINAL
W "ORANGE"
from COMPRESSOR TERMINAL
V "WHITE"
from COMPRESSOR TERMINAL
U "RED"
from CONTROL PWB CN14
from CONTROL PWB BCN1
