Sharp BD-HP90U - Page 37

BD-HP90U
9
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R9040 VRS-CY1JF000JY AA V Resistor 0 1/16W Metal Oxide
R9041 VRS-CY1JF472FY AA V Resistor 4.7k 1/16W Metal Oxide
R9042 VRS-CY1JF391FY AA V Resistor 390 1/16W Metal Oxide
R9043 VRS-CY1JF272FY AA V Resistor 2.7k 1/16W Metal Oxide
R9044 VRS-CZ1JF102JY AA V Resistor 1k 1/16W Metal Oxide
R9045 VRS-TV1JD000JY AA V Resistor 0 1/10W Metal Oxide
R9048 VRS-CZ1JF103JY AA V Resistor 10k 1/16W Metal Oxide
R9053 VRS-CZ1JF105JY AA V Resistor 1M 1/16W Metal Oxide
R9054 VRS-CZ1JF684JY AA V Resistor 680k 1/16W Metal Oxide
R9060 VRS-CZ1JF105JY AA V Resistor 1M 1/16W Metal Oxide
R9061 VRS-CZ1JF684JY AA V Resistor 680k 1/16W Metal Oxide
R9064 VRS-CZ1JF101JY AA V Resistor 100 1/16W Metal Oxide
S2501 QSW-SA033WJQZ N V Switch
SC2501 QSOCN0534FJQ1Y AD V Socket
SC2502 QSOCNA887WJQZ AF V Socket
SC3001 QSOCNA480WJQZY AG V Socket
SC3003 QCNCWA868WJQ1Y N V Connector
SC7201 QSOCZA224WJPZQ AH V Socket
SG7213 RH-VXA187WJQZY AB V Discharge Gap EZAEG2A50AX
SG7214 RH-VXA187WJQZY AB V Discharge Gap EZAEG2A50AX
X7201 RCRSCA205WJQZY AD V Crystal
[3] DUNTKF560TE6A (LED Unit)
C1402 VCEAPF0JW476MY AB J Capacitor 47 6.3V Electrolytic
D1401 RH-PXA176WJPZ+ AE J Diode SLR343BC7TT32(XL,XM)
Q1401 VS2SC4081//-1Y AB J Transistor 2SC4081T106
R1404 VRS-CY1JF271JY AA J Resistor 270 1/16W Metal Oxide
R1405 VRS-CY1JF271JY AA J Resistor 270 1/16W Metal Oxide
R1406 VRS-CY1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R1407 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1408 VRS-TV1JD101JY AA J Resistor 100 1/10W Metal Oxide
RMC1401 RRMCUA087WJQZ AE J Remote Receiver
SC1403 Not Available - - Socket
Note This socket cannot do an individual exchange.
The relevant PWB must be entirely replaced with
new one.
SC1404 QSOCN0534FJQ1Y AD J Socket
[4] DUNTKF561TE6A (OPERATION Unit)
C1201 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C1202 VCEAPF0JW476MY AB J Capacitor 47 6.3V Electrolytic
D1201 RH-PXA174WJQZ+ AC J Diode SLI-343U8RT32(XK)
D1202 RH-PXA146WJPZ+ AC J Diode SLI-343M8CT32(XG,XH)
D1203 RH-PXA146WJPZ+ AC J Diode SLI-343M8CT32(XG,XH)
D1204 RH-PXA146WJPZ+ AC J Diode SLI-343M8CT32(XG,XH)
J1201 QSOCZA153WJQZ AG J Socket
LUG1202 QEARPA210WJQZ+ AB J Lug
P1202 QPLGN0480GEZZ AB J Plug
Q1201 VSDTC114EUA-1Y AB J Transistor DTC114EUAT106
Q1202 VSDTC114EUA-1Y AB J Transistor DTC114EUAT106
Q1203 VSDTC114EUA-1Y AB J Transistor DTC114EUAT106
Q1204 VSDTC114EUA-1Y AB J Transistor DTC114EUAT106
R1201 VRS-TV1JD101JY AA J Resistor 100 1/10W Metal Oxide
R1202 VRS-CY1JF222JY AA J Resistor 2.2k 1/16W Metal Oxide
R1205 VRS-CY1JF221JY AA J Resistor 220 1/16W Metal Oxide
R1207 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R1209 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
RMC1201 RRMCUA089WJQZ N J Remote Receiver
S1201 QSW-KA037WJZZY AC J Switch
S1251 QSW-KA037WJZZY AC J Switch
SC1201 Not Available - - Socket
Note This socket cannot do an individual exchange.
The relevant PWB must be entirely replaced with
new one.
[2] DSETV0218TEVW (MAIN Unit)
