Sharp CD-C1900 User Manual

CD-C606/1900,CP-C606/1900
– 41 –
31* P04/XT1 OPEN — Open
32* XT2 — Open
33 Vss VSS — Ground voltage
34 X1 — Main clock
35 X2 — Main clock
36 P37 CD SLM + Output CD slide motor +
37 P36/BUZ CD SLM - Output CD slide motor -
38 P35/PCL CD PUIN SW Input CD PUIN switch
39 P34/TI2 CD O/C SW Input CD open close switch
40 P33/TI1 CD DISC NO SW Input CD DISC NO. switch
41 P32/TO2 CD U/D SW Input CD UP/DOWN switch
42 P31/TO1 REC/PLAY Output Tape record playback
43 P30/TO0 T_BIAS Output Tape record bias control
44 P03/INTP3/CI0 T T1T2 Output Tape T1/T2 change
45* P02/INTP2 TAMUTE (NC) Output Tape play mute
46 P02/INTP1 SYSTEM STOP Input System stop input
47 P00/INTP0/TI0 REMOCON Input Remocon input
48 IC (Vpp) — IC
49 P72 CAM SW Input Tape cam switch
50 P71 T. SOL Output Tape solenoid control
51 P70 T. MOTOR Output Tape motor control
52 VDD VDD — VDD
53 P127/FIP33 T1 FAS Input Tape full autostop pulse input
54 P126/FIP32 FPA Input Tape A side full proof
55* P125/FIP31 OPEN Output No use
56 P124/FIP30 S MUTE Output System mute
57 P123/FIP29 AC RLY CONT Output AC relay control
58 P122/FIP28 POWER Output (+) power supply
59 P121/FIP27 DIST0 Input Distination input
60 P120/FIP26 SPN_P Input Tuner span change
61 P117/FIP25 P15 Output FL Display segment driver
62 P116/FIP24 P16 Output FL Display segment driver
63 P115/FIP23 P13 Output FL Display segment driver
64 P114/FIP22 P20 Output FL Display segment driver
65 P113/FIP21 P14 Output FL Display segment driver
66 P112/FIP20 P11 Output FL Display segment driver
67 P111/FIP19 P10 Output FL Display segment driver
68 P110/FIP18 P9 Output FL Display segment driver
69 P107/FIP17 P8 Output FL Display segment driver
70 P106/FIP16 P7 Output FL Display segment driver
71 VLOAD VLOAD — FL driver (-) power supply. -30V
72 P105/FIP15 P6 Output FL Display segment driver
73 P104/FIP14 P1 Output FL Display segment driver
74 P103/FIP13 P12 Output FL Display segment driver
75 P102/FIP12 P19 Output FL Display segment driver
76 P101/FIP11 P18 Output FL Display segment driver
77 P100/FIP10 P17 Output FL Display segment driver
78* P97/FIP9 LCK Output FL Display segment driver
79 P96/FIP8 5G Output FL Display segment driver
80 P95/FIP7 6G Output FL Display segment driver
IC701 RH-iX0282AWZZ: System Microcomputer (IX0282AW) (2/2)
Port Name
Terminal Name
Pin No.
Input/Output
Function
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
