PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C606/1900,CP-C606/1900
– 5 –
202 92LCAB3041BS1 J AM Side Panel Ass’y,Left
202- 1 GITAS0062AWSA J AK Side Panel,Left
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3041CS1 J AM Side Panel Ass’y,Right
203- 1 GITAS0063AWSA J AK Side Panel,Right
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 92LCOV3022AS1 J AM CD Tray Cover Ass’y
204- 1 GCOVA1223AWSA J AG Cover,CD Tray
204- 2 GCOVA1224AWSA J AE Cover,CD Tray Panel,Left
204- 3 GCOVA1225AWSA J AE Cover,CD Tray Panel,Right
204- 4 92LBADGE1671A J AC Badge,SHARP
205 GITAR0442AWSA J AH Back Board [CD-C606 for
U.S.A./Central America]
205 GITAR0444AWSA J AH Back Board
[CD-C606 for Canada]
205 GITAR0456AWSA J Back Board [CD-C1900 for
U.S.A./Central America]
205 GITAR0457AWSA J Back Board
[CD-C1900 for Canada]
205 GITAR0458AWSA J Back Board
[CD-C1900 for Mexico]
206 GDORF0072AWSA J AK Cassette Holder,Tape 1
207 GDORF0073AWSA J AK Cassette Holder,Tape 2
208 HDECQ0463AWSA J AE Panel,Cassette Holder,Tape 1
209 HDECQ0464AWSA J AE Panel,Cassette Holder,Tape 2
210 LANGK0170AWFW J AC Bracket,Headphone Support
211 LANGT0049AWFW J AK Bracket,Heat Sink
212 LCHSM0086AWSA J AM Main Chassis
213 LHLDZ1087AWSA J AC Holder,FL Display
214 MLIFP0003AWZZ J AE Damper,Cassette Holder
215 MSPRD0092AWFJ J AB Spring,Cassette Holder Up,
Tape 1
216 MSPRD0093AWFJ J AB Spring,Cassette Holder Up,
Tape 2
218 PRDAR0138AWFW J AH Heat Sink,Main
219 92LRDAT-1468B J AE Heat Sink,Sub
220 92LMECHA2823A J BL Tape Mechanism Ass’y
220- 1(MM1) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
220- 2 NBLTK0011AWZZ J AC Belt,Main [Tape 1]
220- 3 NBLTK0012AWZZ J AB Belt,Main [Tape 2]
220- 4 NBLTK0030AWZZ J AC Belt,Sub
220- 5 NROLY0002AWZZ J AF Pinch Roller
220- 6 92LMRPH1746A J AM Head,Record/Playback
[Tape 1/Tape 2]
220- 7 RHEDA0001AWZZ J AG Head,Erase [Tape 2]
220- 8(SWM3) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
220- 9(SWM4) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
220-10(SWM5) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
221 92LLABL372C J AB Label,Serial No.
[For Canada Only]
222 92LN-BAND1318A J AA Nylon Band,80mm
223 GCAB-1044AWSA J AM CD Player Base
224 GCAB-1052AWSA J AP Top Cabinet
225 LANGF0032AWZZ J AC Support,Turntable Lock Lever
226 LCHSZ0010AWZZ J AM Chassis,Loading
227 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
228 92LHOLD3022AS1 J AB Stabilizer Ass’y
228- 1 ———— — Stabilizer
(Not Replacement Item)
228- 2 PMAGF0001AWZZ J AF Magnet,Stabilizer
228- 3 92LSUPT1749D J AA Support,Stabilizer Magnet
229 LHLDZ1140AWZZ J AB Guide
230 LHLDZ1141AWZZ J AB Support,Pitch
231 LHLDZ1204AWSA J AD Support,Stabilizer
232 MLEVP0066AWZZ J AE Lever,Shift
233 MLEVP0067AWZZ J AC Lever,Lock
234 MLEVP0068AWZZ J AB Lever,Change
235 MLEVP0070AWZZ J AB Lever,Turntable Lock
236 MSPRC0020AWFJ J AB Spring,Turntable Lock Lever
237 MSPRC0024AWFW J AB Spring,Solenoid
238 MSPRD0044AWFJ J AB Spring,Lock Lever
239 NBLTK0033AWZZ J AC Belt,Drive
240 NGERH0064AWZZ J AD Gear,Cam
241 NGERH0065AWZZ J AB Gear,Turntable
242 NGERK0003AWZZ J AC Gear,Drive
243 NGERK0004AWZZ J AB Gear,Bevel
244 NGERK0005AWZZ J AB Gear,Loading
245 NGERW0006AWZZ J AC Gear,Worm Wheel
246 NPLYD0002AWZZ J AC Pulley
247 NROLP0009AWZZ J AB Roller
248 NTNT-0018AWSA J AK Turntable
249 PCOVZ1013AWZZ J AB Cover,Wire
250 TLABN0086AWZZ J AB Label,Production SER.No.
[U.S.A./Central America Only]
! 251 QLUGP0001AWZZ J AC Lug
252 PCUSG0022AWZZ J AB Cushion
253 LHLDZ1230AWZZ J AC Holder,LED
602 XBPSD26P05JSO J AB Screw,ø2.6×5mm
603 XEBSD26P12000 J AA Screw,ø2.6×12mm
604 XEBSD30P10000 J AA Screw,ø3×10mm
605 XEBSD30P12000 J AA Screw,ø3×12mm
606 XEBSF30P12000 J AA Screw,ø3×12mm
607 XESSD30P10000 J AA Screw,ø3×10mm
608 XJBSD30P08000 J AA Screw,ø3×8mm
609 XJBSD30P10000 J AA Screw,ø3×10mm
610 XJBSF30P08000 J AA Screw,ø3×8mm
611 XJSSF30P10000 J AA Screw,ø3×10mm
612 XWHJZ62-09510 J AB Washer,ø6.2×ø10×0.9mm
614 LX-EZ0005AWFD J AA Screw,Special
615 LX-JZ0002AWFD J AA Screw,ø3×10mm
616 LX-JZ0004AWFD J AA Screw,ø3×12mm
618 LX-TZ0019AFZZ J AB Screw,Special
PACKING PARTS (For Canada/Central America)
SPAKA0212AWZZ J AL Packing Add.,Left/Right
SPAKC0746AWZZ J Packing Case
[CD-C606 for Central America]
SPAKC0749AWZZ J Packing Case
[CD-C606 for Canada]
SPAKC0751AWZZ J AR Packing Case
[CD-C1900 for Central America]
SPAKC0752AWZZ J AR Packing Case
[CD-C1900 for Canada]
SPAKP0013AWZZ1 J AC Polyethylene Bag,Unit
TLABR1027AWZZ J AB Label,Bar Code [CD-C1900 for
Central America Only]
TLABR1028AWZZ J AB Label,Bar Code [CD-C606 for
Central America Only]
92LBAG1460C1 J AB Polyethylene Bag,Accessories
ACCESSORIES
! QACCD0015AW00 J AM AC Power Supply Cord
[For Canada]
! QACCD0020AWZZ J AN AC Power Supply Cord
[For U.S.A./Central America]
QANTL0007AWZZ J AK AM/FM Loop Antenna
TINSE0243AWZZ J AE Operation Manual
[CD-C606 for U.S.A.]
TINSE0244AWZZ J AE Operation Manual
[CD-C1900 for U.S.A.]
TINSK0083AWZZ J AH Operation Manual
[CD-C606 for Canada]
TINSK0084AWZZ J AE Operation Manual
[CD-C1900 for Canada]
TINSZ0409AWZZ J AB Quick Guide [CD-C606 for
U.S.A./Central America Only]
TINSZ0410AWZZ J AE Operation Manual
[CD-C1900 for Mexico]
TINSZ0411AWZZ J AB Quick Guide [CD-C1900 for
U.S.A./Central America Only]
TLABZ0527AWZZ J AB Label,Feature,Unit,Tape 1
TLABZ0528AWZZ J AB Label,Feature,Unit,Tape 2
RRMCG0179AWSA J AS Remote Control
GFTAB1022AWSA J Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~4 92LPWB3041MANS J — Main/Display/Headphones/
Switch (Combined Ass’y)
[CD-C606]
PWB-A1~4 92LPWB3042MANS J — Main/Display/Headphones/
Switch (Combined Ass’y)
[CD-C1900]
PWB-B 92LPWB3041CDUS J — CD Servo [CD-C606]
PWB-B 92LPWB3042CDUS J — CD Servo [CD-C1900]
PWB-C QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-D QPWBF0341AWZZ J AB Tray Motor (PWB Only)
PWB-E QPWBF0106AWZZ J AF Tape Mechanism (PWB Only)
