Sharp CD-C410H User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-C410H,CP-C410
R771 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R772 VRD-MN2BD104J J AA 100 kohm,1/8W
R773~775 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R776 VRD-MN2BD820J J AA 82 ohms,1/8W
R777,778 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R779 VRD-MN2BD102J J AA 1 kohm,1/8W
R780,781 VRD-MN2BD103J J AA 10 kohm,1/8W
R782 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R783 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R785 VRD-MN2BD101J J AA 100 ohm,1/8W
R786 VRD-MN2BD102J J AA 1 kohm,1/8W
R788 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R789 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R792 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R793 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R794 VRD-ST2CD123J J AA 12 kohms,1/6W
R795 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R797 VRD-MN2BD102J J AA 1 kohm,1/8W
R798 VRD-MN2BD151J J AA 150 ohms,1/8W
R799 VRD-MN2BD120J J AA 12 ohms,1/8W
R803,804 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R805,806 VRD-MN2BD102J J AA 1 kohm,1/8W
R807,808 VRD-MN2BD181J J AA 180 ohms,1/8W
R809,810 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R811,812 VRD-RT2HD271J J AA 270 ohms,1/2W
R815 VRD-ST2CD103J J AA 10 kohm,1/6W
R825 VRD-ST2EE103J J AA 10 kohm,1/4W
R835,836 VRD-RT2HD331J J AA 330 ohms,1/2W
R843,844 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
R845 VRD-ST2CD100J J AA 10 ohm,1/6W
R943,944 VRD-ST2EE180J J AA 18 ohms,1/4W
R945 VRD-MN2BD333J J AA 33 kohms,1/8W
R946 VRD-ST2EE101J J AA 100 ohm,1/4W
R947 VRD-ST2EE271J J AA 270 ohms,1/4W
R948,949 VRD-MN2BD223J J AA 22 kohms,1/8W
R951 VRD-ST2EE152J J AA 1.5 kohms,1/4W
R952 VRD-ST2CD333J J AA 33 kohms,1/6W
R953 VRD-ST2CD103J J AA 10 kohm,1/6W
R972 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R973 VRD-ST2CD101J J AA 100 ohm,1/6W
R974 VRD-ST2CD123J J AA 12 kohms,1/6W
R975,976 VRD-ST2CD221J J AA 220 ohms,1/6W
R977,978 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
R981,982 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
OTHER CIRCUITRY PARTS
BI901/CNS901 QCNWN0890AWZZ J AE Connector Ass’y,6-6Pin
BIM1/CNSM1 QCNWN0897AWZZ J AF Connector Ass’y,8-12Pin
BIM5/CNS10/CNS5 QCNWN0894AWZZ J AH Connector Ass’y,6-10-2Pin
CNP1 QCNCM931EAFZZ J AC Plug,5Pin
CNP2 92LCONE8P53253 J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP10 92LCONEAP53254 J AD Plug,10Pin
CNP101 QCNCM742CAFZZ J AA Plug,3Pin
CNP102 QCNCM588GAFZZ J AB Plug,7Pin
CNP301 QCNCM602BAFZZ J AA Plug,2Pin
CNP303 QCNCW010KAWZZ J AD Plug,10Pin
CNP402 QCNCM010KAWZZ J AC Plug,10Pin
CNP901 QCNCM742FAFZZ J AB Plug,6Pin
CNPM1 QCNCM932MAFZZ J AE Plug,11Pin
CNPM2 QCNCM030BAWZZ J AB Plug,2Pin
CNS1A/B QCNWN0891AWZZ J AG Connector Ass’y,5-5Pin
CNS2A/B QCNWN0892AWZZ J AF Connector Ass’y,8-8Pin
CNS3A/B QCNWN0893AWZZ J AF Connector Ass’y,6-6Pin
CNS101 QCNWN0895AWZZ J AE Connector Ass’y,3Pin
CNS102 QCNWN0896AWZZ J AG Connector Ass’y,8Pin
F1 92LFUSE-T501E J AD Fuse,T500mA L,250V
F962 92LFUSET252E J AD Fuse,T2.5A L 250V
F963 92LFUSE-T162-E J AD Fuse,T1.6A L 250V
FE301 RTUNS0007AWZZ J AT FM Front End
FL701 VVKFIP9EM7R-1 J AV FL Display
FWM1 QCNWN0328AWZZ J AC Flat Cable,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Cable,2Pin
J801 QJAKM0005AWZZ J AD Jack,Headphones
M1 92LMTR1858CASY J AS Motor with Chassis [Disc]
M2 92LMTR1854BASY J AP Motor with Gear [Slide]
M3 92LMTR2037AS1 J AP Motor with Worm [T/T Up/Down]
MM1 RMOTV0006AWM1 J AR Motor with Pulley [Tape]
RX701 VHLSPSP440/-1 J AH Remote Sensor,SPSP440
SO301 QTANC0103AWZZ J AD Antenna Terminal
SO401 QSOCJ0209AWZZ J AD Jack,VIDEO/AUX.
SO801 QTANA0404AWZZ J AF Terminal,Speaker
SOLM1,2 RPLU-0002AWZZ J AH Solenoid Ass’y
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf Type [Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW701 92LSWICH-1401A J AC Switch,Key Type
[Random/Demo]
SW702 92LSWICH-1401A J AC Switch,Key Type [Volume Down]
SW703 92LSWICH-1401A J AC Switch,Key Type [X-BASS]
SW704 92LSWICH-1401A J AC Switch,Key Type [Volume Up]
SW705 92LSWICH-1401A J AC Switch,Key Type [Open/Close]
SW706 92LSWICH-1401A J AC Switch,Key Type [Disc Skip]
SW709 92LSWICH-1401A J AC Switch,Key Type [Rec./Pause]
SW710 92LSWICH-1401A J AC Switch,Key Type [Up]
SW711 92LSWICH-1401A J AC Switch,Key Type [Stop]
SW712 92LSWICH-1401A J AC Switch,Key Type [Play]
SW713 92LSWICH-1401A J AC Switch,Key Type [Down]
SW714 92LSWICH-1401A J AC Switch,Key Type [Tuning Up]
SW715 92LSWICH-1401A J AC Switch,Key Type [Tuning Down]
SW717 92LSWICH-1401A J AC Switch,Key Type [Power]
SW718 92LSWICH-1401A J AC Switch,Key Type [Clock]
SW719 92LSWICH-1401A J AC Switch,Key Type [Timer/Sleep]
SW721 92LSWICH-1401A J AC Switch,Key Type [Memory/Set]
SW722 92LSWICH-1401A J AC Switch,Key Type [CD]
SW723 92LSWICH-1401A J AC Switch,Key Type [Tuner]
SW724 92LSWICH-1401A J AC Switch,Key Type [Tape]
SW725 92LSWICH-1401A J AC Switch,Key Type [Aux]
SWM3 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4 QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM5 92LM-SW1658A J AB Switch,Leaf Type [CAM]
CASSETTE MECHANISM PARTS
1 LCHSM0014AW01 J AN Main Chassis Ass’y
2 LPLTP0001AWZZ J AD Plate,Head [Tape 1]
3 LPLTP0002AWZZ J AD Plate,Head [Tape 2]
4 NDAIR0004AW01 J AG Take-Up Reel Ass’y [Tape 1]
5 NDAIR0005AW01 J AG Take-Up Reel Ass’y [Tape 2]
6 NGERH0024AWZZ J AB Gear,Supply Reel
7 NROLY0002AWZZ J AF Pinch Roller Ass’y
8 NFLYC0002AWZZ J AG Flywheel Ass’y [Tape 1]
9 NFLYC0003AWZZ J AH Flywheel Ass’y [Tape 2]
10 MLEVP0024AW01 J AH Lever,FF/REW Roller Ass’y
11 NGERH0027AWZZ J AE Gear,Cam
12 NGERH0028AWZZ J AB Gear,Flywheel
13 NGERH0030AWZZ J AE Gear,Play Idler
14 NGERH0032AWZZ J AC Gear,FF
15 NPLYB0004AWZZ J AB Sensor,Wing
16 MLEVP0026AWZZ J AC Lever,Trigger
17 MLEVP0027AWZZ J AC Lever,Lock [Tape 1]
18 MLEVP0028AWZZ J AC Lever,Eject Obstruct [Tape 1]
19 MLEVP0069AWZZ J AB Lever,Eject Obstruct [Tape 2]
20 LHLDS1001AW01 J AE Holder,Bearing
21 PGIDM0007AWZZ J AC Guide,Cassette [Tape 2]
22 PGIDM0009AWZZ J AC Guide,Cassette [Tape 1]
23 MLEVF0004AWFW J AB Lever,Over Strok [Tape 1]
24 MLEVF0005AW01 J AE Lever,Over Strok Ass’y [Tape 2]
25 MLEVF0006AW01 J AD Lever,Mode Ass’y
26 MLEVF0007AW01 J AC Lever,Idler Ass’y [Tape 1]
27 MLEVF0008AW01 J AD Lever,Idler Ass’y [Tape 2]
28 LANGT0025AWFW J AD Blacket Motor
29 LANGT0026AWFW J AC Blacket Hold
30 LANGT0033AWFW J AB Blacket,Switch
31 MSPRP0005AWFW J AB Spring,Cassette
32 MSPRC0008AWFJ J AB Spring,Back Tention
33 MSPRD0031AWFJ J AB Spring,Lock Lever [Tape 1]
34 MSPRD0032AWFJ J AB Spring,Mode Lever
35 MSPRD0033AWFJ J AB Spring,Play Idler Lever
36 MSPRD0034AWFJ J AB Spring,Play Roller
37 MSPRD0035AWFJ J AB Spring,Eject Obstruct [Tape 1]
38 MSPRD0036AWFJ J AB Spring,Play Return
39 MSPRD0037AWFJ J AB Spring,Over Strok Lever
40 MSPRD0038AWFJ J AB Spring,Trigger Lever
41 MSPRD0039AWFJ J AB Spring,FR Lever
42 MSPRD0040AWFJ J AB Spring,Eject Obstruct [Tape 2]
43 NBLTK0009AWZZ J AC Belt,Sub
44 NBLTK0011AWZZ J AC Belt,Main [Tape 1]
45 NBLTK0012AWZZ J AB Belt,Main [Tape 2]
52 92LM-LEV1756A J AB Lever,Lock [Tape 2]
53 92LM-TSPR1756C J AB Spring,Lock Lever [Tape 2]
55 92LMRPH1746A J AM Head,Record/Playback
– 4 –
!
!
!
