CD-C410H,CP-C410
– 5 –
CD-C410H
Rear Panel
1. Video/Auxiliary (Audio Signal) Input Sockets
2. Speaker Terminals
3. AC Power Lead
4. FM 75 ohms Aerial Socket
5. AM Loop Aerial Input Socket
CP-C410
Speaker Section
6. Full Range Speaker
7. Bass Reflex Duct
8. Speaker Wire
1
2
3
4
5
6
7
8
Remote Control
1. Remote Control Transmitter LED
CD Control section
2. Disc Number Select Buttons
3. Track Down/Review Button:
4. Track Up/Cue Button:
5. Disc Skip Button
6. Play/Repeat Button:
7. Stop Button:
8. Memory Button
9. Clear Button
10. Random Button
11. Pause Button:
Tuner control section
12. Preset Up/Down Buttons:
Tape control section
13. (TAPE 1/2) Stop Button:
14. (TAPE 1) Play Button:
15. (TAPE 2) Record Pause Button:
16. (TAPE 2) Play Button:
17. (TAPE 2) Rewind Button:
18. (TAPE 2) Fast Forward Button:
19. Function Selector Buttons
20. Extra Bass/Equalizer Mode Button
21. Power Button
22. Volume Up/Down Buttons:
1
2
3
4
5
6
7
11
12
10
98
14
13
15
19
22
20
18
17
16
21
