– 33 –
CD-C421H / C411H
7
8 9 10 11 12
Figure 33 SCHEMATIC DIAGRAM (7/11)
R981
330
(1/2W)
1
5
1
5
R982
330 (1/2W)
CNS901
S0901
AC POWER
INPUT SOCKET
AC 230V/50Hz
L901 CORE
R972
4.7
CNP901
C948
3300/25
421H ONLY
421H ONLY
D911
RL104A
C908 2.2
F901
T3.15A L 250V
F902
T1.6A L 250V
D905
RL104A
D908
RL104A
C903 47/50
R902 12K
D904
D906
RL104A
D910
RL104A
C909
0.047 (ML)
ZD901
MTZJ6.2A
C906
100/50
C901 100/35
D903
D902
R973 270 (1/2W)
C979
0.1
(ML)
C977
0.1
(ML)
C988
0.047
(ML)
C986
0.022
(ML)
C984
0.022
(ML)
R984
3.3
C989
0.022
(ML)
C987
0.022
(ML)
R985
3.3
C990
0.047
(ML)
R971
4.7
R986
2.2:411H
3.3:421H
R983
2.2:411H
3.3:421H
C985
0.047
(ML)
C991
10/50
(N.P.)
C921
0.022
C924
0.0012:411H
0.001:421H
C923
0.0012:411H
0.001:421H
C925
0.0033
C926
0.0033
C983
0.047
(ML)
C922
0.022
D907
RL104A
D901
D901-D904
RL203F:411H 
1N5402M:422H
R901 220
C902 47/50
R903
220

R905 3.3K
R904 100
ZD902 MTZJ30B
C907 2.2
C904 47/50
R906
2.2
Q901
KTA1266 GR
C905 100/50
C910
0.047 (ML)
C949 2200/50
JK961
HEADPHONES
D909
RL104A
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
7
FW902
PT901
POWER TRANSFORMER
+B
GND
GND
+B
VF1
–VP
VF2
AC POWER CORD
TO FRONT SPEAKER
MIN 5.4 OHMS:421H
MIN 8 OHMS:411H
TO REAR PEAKER
MIN 16 OHMS
R-CH
L-CH
R-CH
L-CH
+
+
+
+
TF901
CHASSIS
GND (D)
HASSIS
ND (D)
LUG962
(258)
UG961
2
58)
(AUDIO)
(AUDIO)
(PWR)
(PWR)
R907
2.2
SO961
SPEAKER TERMINAL
POWER PWB-B
HEADPHONE PWB-A4
R975
270
(1/2W)
–
–
–
–
L963
2.2mH
L961
0.29µH
L962
0.29µH
When Servicing, pay attention as the area enclosed by this line
( ) is directly connected with AC main voltage.
