CD-C421H / C411H
– 46 –
IC601 RH-iX0225AWZZ:Main System Microcomputer (IX0225AW) (1/2)
1* P94 Output Not used OUT:H OPEN
2 P93 T_RECPLY Output REC/P.B Selection
3* P92 Output Not used OUT:H OPEN
4* P91 MUT Output CD Mute Contorol
5 P90 DSPRES Output Reset Output For CD Display
6 P81 SLM2 Output CD Slide Motor–
7 P80 SLM1 Output CD Slide Motor+
8 VDD VDD — Power Terminal
9 SCK0 CD CQCK Output Clock Output For CD
10 SO0 CD COOUT Output Data Output For CD
11 SI0 CD SQIN Input Data Input From CD
12 P24 WRQ Input CD WRQ
13 P23 RWC Output CD WRC
14 SCK1 MAIN SCK Input System Microcomputer Clock
15 SO1 MAIN SO Output System Microcomputer Data Output
16 SI1 MAIN SI Input System Microcomputer Data Input
17 RESET RESET Input Reset
18 P74 MAIN_ST Input System Microcomputer Stove Input
19 P73 PUINSW Input CD PUIN–SW
20 AVSS AVSS — Analog Ground
21 P17 FRF Input Detecting of CD RF Level
22 P16 T1FAS Input TAPE1 Full Auto Stop, Pulse Input
23 ANI5 T2 RUN Input TAPE2 RUN Pulse Input
24-28 ANI4-0 Output Not used OUT:H OPEN
29 AVDD AVDD — Analog VDD
30 AVREF AVREF — Analog Ref Potential
31 P04 CAM SW Input TAPE CAM–SW
32* XT2 Output Not used OPEN
33 VSS VSS — GND Potential
34 X1 X1 Input Main Clock 4.19MHz
35 X2 X2 Output Main Clock 4.19MHz
36* P37 LMUTE Output LINE MUTE
37*-38* P36-35 Output Not used OUT:H OPEN
39* P34 SMUTE Output System Mute
40* P33 Output Not used OUT:H OPEN
41*-43* P32-30 Output Not used OUT:L OPEN
44 P03 SP_DET Input Detecting of SP Output Error
45 P02 STANBY Output Setting Power Control
46* P01 SPRLY Output SP Output Relay Control
47 P00 T2CRO2 Input TAPE2 Detecting of Chrome Tape
48 IC IC Internally Connected
49* P72 Output Not used OUT:L OPEN
50 P71 T_SOL Output TAPE Solenoid Control
51 P70 T_MOTOR Output TAPE Motor Control
52 VDD VDD +Power Supply
53 P127 Input CD TRAY Open/Close SW
54 P126 Input CD TRAY Disc No,SW
55 P125 Input CD Mechanizm Detecting of Up/Down chucking
56 P124 T1CRO2 Input TAPE1 Detecting of CrO2 TAPE
57*-60* P123-120 Output Not used OUT:H OPEN
61* P117 Output Not used OUT:H OPEN
62* P116 SPN_P Input Tuner Span Selection
Port Name
Terminal Name
Pin No.
Input/Output
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Function
