Sharp CD-C422 - Page 8

CD-C422/C422C/C2800/C2800C
– 8 –
( E3 ) x1

( F1 ) x2
ø3x10mm

( G1 ) x6
ø3x10mm

Tape
Mechanism
Cassette
Holder
Front Panel
Power Supply 
PWB
Open
( J1 ) x1
ø2 x 4mm
( J1 ) x1
ø2 x 4mm
( H1 ) x1
ø3 x10mm
Turntable
Disc Tray
( H2 ) x1
( J2 ) x1
( J2 ) x1
CD Player Unit
Washer
Figure 8-1
Figure 8-2
Be careful when installing the CD changer mechanism.
Install the CD changer mechanism on the CD player base after
the shift lever has been set in the highest position.
Figure 8-3
Figure 8-4
( E3 ) x2

( E3 ) x1

( E1 ) x1
ø3 x 8mm
( E2 ) x1
ø3 x10mm
( E1 ) x3
ø3 x10mm
( E1 ) x2
ø3 x10mm
Main PWB
Display
PWB
Switch PWB
Front Panel
( K1 ) x4
ø2.6 x 5mm
(L1 ) x1
ø2.6 x10mm
CD Changer
Mechanism
CD Mechanism
Shift Lever
CD Player Base
