CD-C430H,CP-C430H
– 41 –
FL701 : VVKFiP9EM7R-1 FL Display
Figure 41-2 FL DISPLAY
1 2 3
REC X-BASS SLEEP
ST MEMORY
WIDE
TA
kHz
MHz
NR
SRS
TP
RDS
DOLBY
WIRING OF PRIMARILY SUPPLY LEADS (FOR UK ONLY)
Figure 41-3
If any one of the bands shown in Fig. 41-3 is removed for some
reason, be sure replace it to the original position and same
appearance as before.
Power
Transformer
Nylon Band 80mm
92LN-BAND 1318A
AC Power
Supply Cord
Brown
Blue
Core
IC5 VHiM5674FP-1:Focus/Tracking/Spin/Slide Driver (M5674FP)
Figure 41-1 BLOCK DIAGRAM OF IC
OP1
15K 15K
25K
23K
TSD
1
19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
Regbase Vcc Vctl3(+) Vctl3(-) Vctl3(out) VM3(-) VM3(+)
GND
VM4(+) VM4(-) Vctl4(-) Gain4 Standby SS.GND Standby
2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
Vrel-in
Vrel-out
N.C
Gain1
Vctl(-)
VM1(-)
VM1(+)
GND
VM2(+)
VM2(-)
Vctl2(-)
Gain2
N.C
Vcc
Reg5V
Stand
by
OP1 OP1
PA PA
PA PA
10K 10K 10K 10K
10K
Vcc
10K
10.8K 3.6K
10K 10K
OP1
OP1
OP1
PA PA
PA PA
