Sharp CD-C451H

– 3 –
CD-C451H
SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
Specifications for this model are subject to change without
prior notice.
CD-C451H
General
Power source: AC 230-240 V, 50 Hz
Power
consumption: 81 W
Dimensions: Width; 270 mm (10-5/8")
Height; 303 mm (11-13/16")
Depth; 350 mm (13-13/16")
Weight: 6.6 kg (14.2 lbs.)
Amplifier section
Output power:
( Except FOR GERMANY )
( Except FOR GERMANY )
Output power:
(FOR GERMANY)
MPO; 176 W (88 W + 88 W)
(10 % T.H.D.)
RMS; 80 W (40 W + 40 W)
(10 % T.H.D.)
Input terminals: Video/Auxiliary (audio sig-
nal) ¥ 2; 500 mV/47 kohms
Output terminals: Speakers; 6 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
Pre-output; 500 mV/47
kohms
Compact disc player section
Type: 3-disc multi-play compact
disc player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A converter: 1-bit D/A converter
Frequency
response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
Tuner section
Frequency range: FM; 87.5 - 108 MHz
MW; 522 - 1,620 kHz
LW; 153 - 281 kHz
Cassette deck section
Type: Compact cassette tape
Frequency response: 50 - 14,000 Hz (Normal tape)
Motor: DC motor with electronic governor ¥ 1
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Bias and erasure
system:
AC
Tape speed: 4.76 cm/sec. (1-7/8 ips.)
Wow and flutter: 0.15 % (WRMS)
(FOR GERMANY)
Wow and flutter:
Heads: TAPE-1: Playback 1
TAPE-2: Record/playback ¥ 1
Erase ¥ 1
Speaker section
Type: 3-way type [130 mm (5-1/8") woofer,
50 mm (2") tweeter and super tweeter]
Maximum input power: 80 W
Impedance: 6 ohms
Dimensions: Width; 200 mm (7-7/8")
Height; 300 mm (11-13/16")
Depth; 253 mm (10")
Weight: 2.7 kg (5.8 lbs.)/each
PMPO; 352 W (total)
MPO; 176 W (88 W + 88 W)
(DIN 45 324)
RMS; 80 W (40 W + 40 W)
(DIN 45 324)
0.2 % (DIN 45 511, playback)
CP-C451H
