CD-C471H
Rear Panel
1. CD Digital Output Socket
2. AC Power Input Socket
3. MW/LW Loop Aerial Input Socket
4. FM 75 ohms Aerial Socket
5. Video/Auxiliary (Audio Signal) Input Sockets
6. Sub Woofer Output Socket
7. Front Speaker Terminals
8. Center Speaker Terminals
9. Surround Speaker Terminals
Speaker Section
Front Speaker
1. Super Tweeter
2. Tweeter
3. Woofer
4. Bass Reflax Duct
5. Speaker Wire
Center Speaker
6. Full-Range Speaker
7. Speaker Wire
Surround Speaker
8. Full-Range Speaker
9. Speaker Wire
Remote Control
1. Remote Control Transmitter LED
2. Surround Level Buttons:
3. Center Level Buttons:
4. Dolby Pro Logic Button
5. Center Mode Button
6. Test Tone Button
7. Balance Control Buttons:
Tuner control section
8. Programme Type/Traffic Information
Search Button
9. Preset Up/Down Buttons:
CD Control section
10. Disc Skip Button
11. Play/Repeat Button:
12. Memory Button
13. Clear Button
14. Pause Button:
15. Track Down/Review Button:
16. Track Up/Cue Button:
17. Stop Button:
18. Random Button
CD-C471H
CD-C471H
1
2
3
4
5
6
7
89
1
5
3
4
2
6
7
8
9
Left speaker
Right speaker
1
2
3
4
5
6
8
7
9
10
12
13 14
15 16
17
18
19
20
21
22
25
26
27
28
23
24
29
11
Tape control section
19. (TAPE 2) Reverse Play Button:
20. (TAPE 1/2) Stop Button:
21. (TAPE 1) Play Button/
(TAPE 2) Forward Play Button:
22. (TAPE 2) Record Pause Button:
23. (TAPE 2) Rewind Button:
24. (TAPE 2) Fast Forward Button:
Common section
25. Equalizer Mode Button
26. Function Selector Buttons
27. On/Stand-by Button
28. Extra Bass Button: X-BASS
29. Volume Up/Down Buttons:
CP-C471H
GBOXS0006AWM5
GBOXS0007AWM5
To Next Page
