NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PART CODE
PRICE
RANK
DESCRIPTION
CD-C462
SW4 QSW-F9001AW01 J Switch,Leaf Type [Pickup In]
CABINET PARTS
201 GCAB-1044AWSA J AM Cabinet,CD Player Base
202 GCAB-1050AWSA J AP Top Cabinet
203 GITAR0316AWSA J AS Back Board
204 HDECQ0298AWSA J AK Display Panel
205 JKNBZ0475AWSA J AD Button,X-Bass
207 LANGF0032AWZZ J AC Support,T/T Lock Lever
208 LANGK0114AWFW J AF Bracket,Fan
209 LCHSM0068AWFW J AR Main Chassis
210 LCHSZ0010AWZZ J AM Chassis,Loading
211 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
212 LHLDZ1139AWSA J AD Support,Stabilizer
213 LHLDZ1140AWZZ J AB Guide
214 LHLDZ1141AWZZ J AB Support,Pitch
215 LHLDZ1186AWZZ J AD Holder,FL Display
216 MLEVP0066AWZZ J AE Lever,Shift
217 MLEVP0067AWZZ J AC Lever,Lock
218 MLEVP0068AWZZ J AB Lever,Change
219 MLEVP0070AWZZ J AB Lever,T/T Lock
220 MLIFP0003AWZZ J AE Damper
221 MSPRC0020AWFJ J AB Spring,T/T Lock Lever
222 MSPRC0024AWFW J AB Spring,Solenoid
223 MSPRD0044AWFJ J AB Spring,Lock Lever
224 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
225 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
226 NBLTK0029AWZZ J AB Belt,Drive
227 NFANP0001AWZZ J AD Rotary Fan
228 NGERH0064AWZZ J AD Gear,Cam
229 NGERH0065AWZZ J AB Gear,Turntable
230 NGERK0003AWZZ J AC Gear,Drive
231 NGERK0004AWZZ J AB Gear,Bevel
232 NGERK0005AWZZ J AB Gear,Loading
234 NGERW0006AWZZ J AC Gear,Worm Wheel
235 NPLYD0001AWZZ J AB Pulley
236 NROLP0009AWZZ J AB Roller
237 NTNT-0018AWSA J AK Turntable
238 PCUSG0022AWZZ J AB Cushion
239 PRDAR0115AWFW J AY Heat Sink A
240 PRDAR0107AWFW J AP Heat Sink B
244 92LCAB2743AS1 J Front Panel Ass’y
244- 1 ———— — Front Panel
(Not Replacement Item)
244- 2 HDECQ0299AWSA J AG CD Top Panel
244- 3 92LBADGE1671A J AC Badge,SHARP
244- 4 JKNBZ0472AWSA J AF Button [CD DISC NUMBER]
244- 5 JKNBZ0473AWSA J AD Button [OPEN/CLOSE]
244- 6 JKNBZ0474AWSA J AG Button [FUNCTION]
244- 7 JKNBZ0476AWSA J AF Button [DOLBY/
CENTER MODE]
244- 8 JKNBZ0477AWSA J AD Button [CLOCK/TIMER/SLEEP]
244- 9 JKNBZ0478AWSA J AE Button [TUNING/TIME/
MEMORY/SET]
244-10 JKNBZ0479AWSA J AD Button [CLEAR/RANDOM]
244-11 JKNBZ0480AWSA J AE Button [CD PAUSE]
244-12 JKNBZ0481AWSA J AE Button [OPERATION A]
244-13 JKNBZ0482AWSA J AE Button [OPERATION B]
244-14 JKNBZ0483AWSA J AG Button [OPERATION C]
244-15 PCUSG0022AWZZ J AB Cushion,Leg
245 QCNWN0769AWZZ J AD Wire Lug
247 QLUGP0002AWZZ J AB LugTerminal [Lug 1]
! 248 QFSHD0001AWZZ J AB Holder,Fuse
249 92LCAB2744BS1 J AP Side Panel Ass’y,Left
249- 1 ———— — Side Panel,Left
(Not Replacement Item)
249- 2 PCUSG0022AWZZ J AB Cushion,Leg
250 92LCAB2744CS1 J AP Side Panel Ass’y,Right
250- 1 ———— — Side Panel,Right
(Not Replacement Item)
250- 2 PCUSG0022AWZZ J AB Cushion,Leg
251 92LCOV2744AS1 J AN Cover Ass’y,CD Tray
251- 1 ———— — Cover,CD Tray
(Not Replacement Item)
251- 2 GCOVA1186AWSA J AE Cover,CD Tray Panel Left
251- 3 GCOVA1187AWSA J AE Cover,CD Tray Panel Right
252 92LCSPR1431C J AA Ring,Spring
253 92LLABL1784F J AC Label,UL Caution
254 92LMECHA2744A J Cassette Mechanism Ass’y
254- 1 NBLTK0011AWZZ J AC Belt,Main [Tape1]
254- 2 NBLTK0012AWZZ J AB Belt,Main [Tape2]
254- 3 NBLTK0030AWZZ J AC Belt,Sub
254- 4 NROLY0002AWZZ J AF Pinch Roller Ass’y
254- 5 RHEDA0001AWZZ J AG Head,Erase
254- 6 92LMRPH1746A J AM Haed,Record/Playback
[Tape 1/Tape 2]
254- 7 RMOTV0006AWM1 J AR Motor with Pulley [TAPE], [MM1]
254- 8 RPLU-0002AWZZ J AH Solenoid Ass’y [TAPE], [SOLM1]
255 92LMEC2744CTS1 J AM Cassette Holder Ass’y,Tape 1
255- 1 ———— — Cassette Holder,Tape 1
(Not Replacement Item)
255- 2 HDECQ0296AWSA J AF Panel,Cassette,Tape 1
256 92LMEC2744CTS2 J AM Cassette Holder Ass’y,Tape 2
256- 1 ———— — Cassette Holder,Tape 2
(Not Replacement Item)
256- 2 HDECQ0297AWSA J AF Panel,Cassette,Tape 2
257 92LHOLD2037AS1 J AK Stabilizer Ass’y
257- 1 ———— — Stabilizer
(Not Replacement Item)
257- 2 PMAGF0001AWZZ J AF Magnet
257- 3 92LSUPT1749D J AA Support,Magnet
258 92LN-BAND1318A J AA Nylon Band,80mm
601 LX-EZ0005AWFD J AA Screw,Special
602 LX-HZ0082AFZZ J AA Screw,ø4×8mm
603 LX-JZ0002AWFD J AA Screw,ø3×10mm
604 LX-JZ0010AFFD J AA Screw,ø3×10mm
605 LX-JZ0039AFFD J AA Screw,ø3×12mm
606 LX-LZ0006AWZZ J AC Push Rivet
607 LX-TZ0019AFZZ J AB Screw,Special
608 XBBSD20P04000 J AA Screw,ø2×4mm
609 XBPSD26P05JS0 J AB Screw,ø2.6×5mm
610 XEBSD26P12000 J AA Screw,ø2.6×12mm
611 XEBSD30P10000 J AA Screw,ø3×10mm
612 XEBSD30P12000 J AA Screw,ø3×12mm
613 XEBSF30P10000 J AA Screw,ø3×10mm
614 XEBSF30P12000 J AA Screw,ø3×12mm
615 XESSD30P10000 J AA Screw,ø3×10mm
616 XJBSD30P08000 J AA Screw,ø3×8mm
617 XJBSD30P10000 J AA Screw,ø3×10mm
618 XJBSD30P14000 J AA Screw,ø3×14mm
619 XJBSF30P08000 J AA Screw,ø3×8mm
620 XJSSF30P10000 J AA Screw,ø3×10mm
621 XWHJZ62-09510 Washer,ø6.2×ø10×0.9mm
SPEAKER BOX PARTS
900 92L100R2C46210 J Wood Box Cabinet Ass’y.,Right
900 92L100L2C46210 J Wood Box Cabinet Ass’y.,Left
901 92L201L0C46210 J AV Net Frame Ass’y.,Left
901 92L201R0C46210 J AV Net Frame Ass’y.,Right
902 92L20200C46200 J AR Baffle Board
903 92L23056121000 J AD Holder,Catcher
904 92L303R0300110 J AN Super Tweeter Ass’y.
905 92L3141PC46210 J Speaker Cord Ass’y.
906 92L411B840140B J AC Screw,ø4×14mm
907 92L411B930100P J AC Screw,ø3×10mm
908 92L44010213300 J AH Port Cushion
909 92L44210310100 J AD Wire Cushion
910 92L6000PC46200 J AD Label,Specifications
SP1,2 VSP0013WBK96F J BD Woofer
SP3,4 VSP0050TB256F J AS Tweeter
SPEAKER BOX PARTS CENTER SPEAKER GBOX0006AWM4
900 92L60-00-0150 J Net Frame Ass’y.
901 92L37-03-0010 J Speaker Cord
902 92L32-01-0160 J Bottom Cabinet Ass’y.
903 92L33-01-0350 J AC Label,Parts Code
904 92L35-02-0070 J Screw,ø3×20mm
905 92L35-02-0080 J Screw,ø3×20mm
906 92L39-01-0010 J Leg,Cushion
SP1 92L90-10-2724 J Speaker,Full-range
SPEAKER BOX PARTS REAR SPEAKER GBOX0007AWM4
900 92L60-00-0160 J AW Net Frame Ass’y.
901 92L37-03-0030 J Speaker Cord
902 92L32-01-0170 J Bottom Cabinet Ass’y.
903 92L35-02-0070 J Screw,ø3×20mm
904 92L33-01-0360 J Label,Parts Code
SP1,2 92L90-10-2723 J Speaker,Full-range
– 6 –
