CD-C462
! R912,913 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R914 VRD-ST2CD153J J AA 15 kohms,1/6W
R915 VRD-ST2CD224J J AA 220 kohms,1/6W
R916 VRD-ST2CD102J J AA 1 kohm,1/6W
R917 VRD-ST2CD563J J AA 56 kohms,1/6W
R918 VRD-ST2CD471J J AA 470 ohms,1/6W
R919,920 VRD-ST2CD333J J AA 33 kohms,1/6W
R921 VRD-ST2CD103J J AA 10 kohm,1/6W
R922 VRD-ST2CD471J J AA 470 ohms,1/6W
R923 VRD-ST2CD563J J AA 56 kohms,1/6W
R924~926 VRD-ST2CD102J J AA 1 kohm,1/6W
R928,929 VRD-ST2CD181J J AA 180 ohms,1/6W
R932 VRD-ST2CD183J J AA 18 kohms,1/6W
R933 VRD-ST2CD103J J AA 10 kohm,1/6W
R934 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R937 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R941,942 VRD-RT2HD271J J AA 270 ohms,1/2W
R944 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R949 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R962 VRD-ST2CD821J J AA 820 ohms,1/6W
R964,965 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R966 VRD-ST2CD153J J AA 15 kohms,1/6W
R967 VRD-ST2CD683J J AA 68 kohms,1/6W
R968 VRD-ST2CD102J J AA 1 kohm,1/6W
R969 VRD-RT2HD680J J AA 68 ohms,1/2W
RD01 VRD-ST2CD102J J AA 1 kohm,1/6W
RD02 VRD-MN2BD122J J AA 1.2 kohms,1/8W
RD03 VRD-MN2BD182J J AA 1.8 kohms,1/8W
RD04 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD05 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD06 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD07 VRD-ST2CD123J J AA 12 kohms,1/6W
RD08 VRD-ST2CD333J J AA 33 kohms,1/6W
RD09 VRD-ST2CD102J J AA 1 kohm,1/6W
RD10 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD11 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD12 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD13 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD14 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD15 VRD-ST2CD102J J AA 1 kohm,1/6W
RD16 VRD-MN2BD122J J AA 1.2 kohms,1/8W
RD17 VRD-MN2BD182J J AA 1.8 kohms,1/8W
RD18 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD19 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD20 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD21 VRD-MN2BD123J J AA 12 kohms,1/8W
RD22 VRD-ST2CD102J J AA 1 kohm,1/6W
RD23 VRD-MN2BD122J J AA 1.2 kohms,1/8W
RD24 VRD-MN2BD182J J AA 1.8 kohms,1/8W
RD25 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD26 VRD-MN2BD392J J AA 3.9 kohms,1/8W
OTHER CIRCUITRY PARTS
BI601/CNS11 QCNWN1185AWZZ J AG Connector Ass’y,6-6Pin
BI701/CNSM1 QCNWN1189AWZZ J AH Connector Ass’y,8-12Pin
BI702/CNS12 QCNWN1186AWZZ J AL Connector Ass’y,14-14Pin
BIM5/CNS10/CNS QCNWN1184AWZZ J AL Connector Ass’y,6-10-2Pin
CNP1 92LCONE5P53253 J AB Plug,5Pin
CNP2 QCNCM705HAFZZ J AB Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP10 QCNCM705KAWZZ J AC Plug,10Pin
CNP11 QCNCM704FAWZZ J AC Plug,6Pin
CNP12 QCNCM704PAWZZ J AE Plug,14Pin
CNP101 92LCONE3P53253 J AB Plug,3Pin
CNP102 92LCONE7P53253 J AC Plug,7Pin
CNP301 92LCONE-3P5268 J AC Plug,3Pin
CNP601 QCNCWZG27AWZZ J AE Socket,27Pin
CNP801 QCNCM036BAWZZ J AC Plug,2Pin
CNP802 QCNCM035JAWZZ J AC Plug,9Pin
CNP803 QCNCM010VAWZZ J AD Plug,20Pin
CNP804 92LCONE2P53253 J AB Plug,2Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Holder, 2Pin
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5-5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8-8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6-6Pin
CNS101 QCNWN1187AWZZ J AG Connector Ass’y,3Pin
CNS102 QCNWN1188AWZZ J AM Connector Ass’y,7Pin
CNS701 QCNCWZF27AWZZ J AE Socket,27Pin
CNS803 QCNCW010VAWZZ J AE Socket,20Pin
CNS804 QCNWN1200AWZZ J AD Connector Ass’y,2Pin
! F802~804 92LFUSE-T402D J AD Fuse,4A/125V
! F805 92LFUSE-T162-D J AD Fuse,1.6A/250V
! F901,902 92LFUSE-T502D J AD Fuse,5A/250V
FL701 VVKFIP9EM7R-1 J AV FL Display
FW601 QCNWN1190AWZZ J AH Flat Cable,27Pin
FW701 QCNWN1191AWZZ J AD Flat Cable,3Pin
FWM1 QCNWN1274AWZZ J AC Flat Cable,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Cable,2Pin
JK451 QSOCJ0104AWZZ J AD Socket,Sub Woofer Output
JK601 QSOCJ0211AWZZ J AE Socket,Video/Aux
JK701 QJAKM0008AWZZ J AF Jack,Headphone
M1 92LMTR1858CASY J AS Motor with Chassis [Disc]
M2 92LMTR1854BASY J AP Motor with Gear [Slide]
M3 92LMTR2037AS1 J AP Motor with Worm Pulley
[T/T Up/Down Loading]
M901 92LMTR1810A J AK Motor,Air Cooling Fan
MM1 RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Photo Interrupter
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
! SO801 QSOCA0209AWZZ J AH Socket,AC Power Input
SO901 QTANA1001AWZZ J AC Terminal,Speaker
SOLM1 RPLU-0002AWZZ J AH Solenoid Ass’y [TAPE]
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y [CD]
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf Type [Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type
[P.O.EQ./Demo]
SW702 92LSWICH1401AT J AC Switch,Key Type [Volume Down]
SW703 92LSWICH1401AT J AC Switch,Key Type [X-Bass]
SW704 92LSWICH1401AT J AC Switch,Key Type [Volume Up]
SW705 92LSWICH1401AT J AC Switch,Key Type [Open/Close]
SW706 92LSWICH1401AT J AC Switch,Key Type [Disc Skip]
SW707 92LSWICH1401AT J AC Switch,Key Type [Disc 1]
SW708 92LSWICH1401AT J AC Switch,Key Type [Disc 2]
SW709 92LSWICH1401AT J AC Switch,Key Type [Disc 3]
SW710 92LSWICH1401AT J AC Switch,Key Type [Rec/Pause]
SW711 92LSWICH1401AT J AC Switch,Key Type [Preset Up]
SW712 92LSWICH1401AT J AC Switch,Key Type [Stop]
SW713 92LSWICH1401AT J AC Switch,Key Type [Play/Repeat]
SW714 92LSWICH1401AT J AC Switch,Key Type [Preset Down]
SW715 92LSWICH1401AT J AC Switch,Key Type [Tuning Up]
SW716 92LSWICH1401AT J AC Switch,Key Type [Tuning Down]
SW717 92LSWICH1401AT J AC Switch,Key Type [Power]
SW718 92LSWICH1401AT J AC Switch,Key Type [Clock]
SW719 92LSWICH1401AT J AC Switch,Key Type [Timer/Sleep]
SW720 92LSWICH1401AT J AC Switch,Key Type [Memory/Set]
SW721 92LSWICH1401AT J AC Switch,Key Type [CD]
SW722 92LSWICH1401AT J AC Switch,Key Type [Tuner/Band]
SW723 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW724 92LSWICH1401AT J AC Switch,Key Type [VIDEO AUX]
SW725 92LSWICH1401AT J AC Switch,Key Type
[BYPASS,DOLBY]
SW726 92LSWICH1401AT J AC Switch,Key Type [Normal]
SW727 92LSWICH1401AT J AC Switch,Key Type [Phantom]
SW728 92LSWICH1401AT J AC Switch,Key Type [CD Pause]
SW729 92LSWICH1401AT J AC Switch,Key Type [CD Clear]
SW730 92LSWICH1401AT J AC Switch,Key Type [Random]
SWM3 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4 QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S]
SWM5 92LM-SW1658A J AB Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1858CASY J AS Motor with Chassis [Disc]
M2 92LMTR1854BASY J AP Motor with Gear [Side]
– 5 –
