Sharp CD-C470W User Manual

CD-C407W,CP-C407
– 2 –
C359,360 RC-GZA335AF1E J VCEAZA1HW335M J 3.3 µF, 50V, Electrolytic AB
C362 RC-GZA335AF1E J VCEAZA1HW335M J 3.3 µF, 50V, Electrolytic AB
C384 RC-GZA476AF1C J VCEAZA1EW476M J 47 µF, 25V, Electrolytic AB
C465~468 RC-GZA106AF1C J VCEAZA1HW106M J 10 µF, 50V, Electrolytic AB
C706 RC-GZA335AF1E J VCEAZA1HW335M J 3.3 µF, 50V, Electrolytic AB
C712 RC-GZA476AF1C J VCEAZA1EW476M J 47 µF, 25V, Electrolytic AB
C713 RC-GZA106AF1C J VCEAZA1HW106M J 10 µF, 50V, Electrolytic AB
C904,905 RC-QZA224AFYJ J VCFYHA1HA224J J 0.22 µF, 50V, Thin Film AC
C923 RC-QZ0026AWZZ J VCQYKA1HM473K J 0.047 µF, 50V, Mylar AB
C926,927 RC-GZA476AF1C J VCEAZA1EW476M J 47 µF, 25V, Electrolytic AB
PART NO.
REF.
NO.
CODE
PART NO.
CAPACITORS
DESCRIPTION
MARK: SPARE PARTS-DELIVERY SECTION
RESISTORS
R93 VRD-ST2EE4R7J J Not Used 4.7 ohms, 1/4W —
R94 Not Used VRD-ST2EE560J J 56 ohms, 1/4W AA
R355 VRD-MN2BD103J J Not Used 10 kohm, 1/8W —
R356 VRD-MN2BD473J J Not Used 47 kohms, 1/8W —
R391 VRD-ST2CD472J J VRD-ST2CD473J J 47 kohms, 1/6W AA
R398 VRD-ST2CD472J J Not Used 4.7 kohms, 1/6W —
R709,710 VRD-MN2BD103J J Not Used 10 kohm, 1/8W —
R713 VRD-MN2BD103J J Not Used 10 kohm, 1/8W —
! R766 VRD-RT2HD100J J VRG-ST2EC100J J 10 ohm, 1/4W, Fusible AB
CABINET PARTS
201 92LCAB2450AS1 J 92LCAB2792AS1 J Front Panel Ass'y AV
201-1 ———————— ———————— Front Panel (Not Replacement Item) —
201-2 HDECQ0248AWSA J HDECQ0360AWSA J Panel, Display AG
201-3 Not Used GCoVA1204AWSA J Cover, Remote Sensor AD
202 GiTAR0250AWSA J GiTAR0346AWSA J Back Board [Except for Thailand] AH
202 GiTAR0251AWSA J GiTAR0347AWSA J Back Board [For Thailand] AH
206 GCoVA1148AWSA J GCoVA1211AWSA J Cover, CD Tray AH
209 JBTN-0106AWSA J JBTN-0117AWSA J Button, Record [Tape 1] AD
210 JBTN-0104AWSA J JBTN-0118AWSA J Button, Play [Tape 1] AD
211 JBTN-0107AWSA J JBTN-0119AWSA J Button, Rewing [Tape 1] AD
212 JBTN-0103AWSA J JBTN-0120AWSA J Button, Fast Forward [Tape 1] AD
213 JBTN-0108AWSA J JBTN-0121AWSA J Button, Stop [Tape 1] AD
214 JBTN-0105AWSA J JBTN-0122AWSA J Button, Play [Tape 2] AD
217 JBTN-0109AWSA J JBTN-0123AWSA J Button, Stop [Tape 2] AD
227 PCUSG0027AWZZ J Not Used Worm Wheel Cushion —
236 MSPRC0021AWFJ J Not Used Spring, Worm Wheel —
248 92LMEC2448CTS1 J 92LCoV2790CTS1 J Cassette Cover Ass'y, Tape1 AM
248-1 ———————— ———————— Cassette Cover,Tape1(Not Replacement Item) —
248-2 HDECQ0206AWSA J HDECQ0352AWSA J Panel,Cassette,Tape1 AD
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
!
OTHER CIRCUITRY PARTS
CNP902 QCNCM036EAWZZ J QCNCM042EAWZZ J Plug, 5Pin AB
CNS201 QCNWN0919AWZZ J QCNWN0634AWZZ J Connector Ass'y, 3Pin AK
CNS202 QCNWN0920AWZZ J QCNWN0635AWZZ J Connector Ass'y, 7Pin AQ
SW4 QSW-F9001AWZZ J QSW-F9001AW01 J Switch, Push Type [Pickup In] AD
SW608 QSW-F0346AFZZ J 92LM-SW1658A J Switch, Leaf Type [Tape 1 Play] AB
SW701 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Power] AD
SW702 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Volume Up] AD
SW703 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Volume Down] AD
SW704 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Play] AD
SW705 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Fast Forward] AD
SW706 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Rewind] AD
SW707 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Open/Close] AD
SW708 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Stop] AD
SW709 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Disc Skip] AD
SW710 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [X-BASS] AD
SW711 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Function Selector] AD
SW712 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Band Selector] AD
SW713 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Clock/Timer] AD
SW714 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Memory] AD
SW715 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Tuning Up] AD
SW716 QSW-K0181AFZZ J 92LSWICH1401A J Switch, Key Type [Tuning Down] AD
CD-C401W CD-C407W
