CD-C407W,CP-C407
– 3 –
249 92LMEC2448CTS2 J 92LCoV2790CTS2 J Cassette Cover Ass'y, Tape2 AM
249-1 ———————— ———————— Cassette Cover,Tape2(Not Replacement Item) —
249-2 HDECQ0207AWSA J HDECQ0353AWSA J Panel,Cassette,Tape2 AD
251 HDECQ0208AWSA J JKNBZ0528AWSA J Knob, Stop AF
252 JKNBZ0378AWSA J JKNBZ0527AWSA J Knob, Function AG
253 JKNBZ0380AWSA J JKNBZ0524AWSA J Knob, Volume AF
254 JKNBZ0381AWSA J JKNBZ0525AWSA J Knob, X-BASS AE
255 JKNBZ0406AWSA J JKNBZ0536AWSA J Knob, Power AG
258 TLABS0138AWZZ J TLABS0159AWZZ J Label, CPA
259 TSPC-0464AWZZ J TSPC-0501AWZZ J Label, Specifications [For Thailand] AD
259 TSPC-0469AWZZ J TSPC-0502AWZZ J Label, Specifications [For Taiwan] AC
260 TCAUS0014AWZZ J TCAUS0040AWZZ J Label, Warning [For Taiwan] AB
267 Not Used XWHJZ62-09510 J Washer, ø 6.2 x ø 10 x 0.9 mm AB
268 Not Used LANGF0032AWZZ J Support, T/T Lock Lever AC
269 Not Used GDoRF0060AWSA J Cassette Holder, Tape 1 AF
270 Not Used GDoRF0061AWSA J Cassette Holder, Tape 2 AF
271 Not Used QLUGP0001AWZZ J Lug AC
272 Not Used PSPAi0014AWZZ J Spacer, Power Transformer AD
603 XEBSD30P12000 J XEBSD30P16000 J Screw, ø3 x 16 mm AA
604 XJBSD30P08000 J Not Used Screw, ø3 x 8 mm —
613 XJBSF30P10000 J Not Used Screw, ø3 x 10 mm —
REF.
NO.
CD-C407W
PART NO.
CABINET PARTS
DESCRIPTION
QACCB0004AW00 J QACCB0002AW00 J AC Power Supply Cord [For Hong Kong] AY
QACCE0007AW00 J QACCE0005AW00 J AC Power Supply Cord [Except for Australia/ AM
New Zealand/Hong Kong]
SPAKA0135AWZZ1 J SPAKA0196AWZZ J Packing Add., Left/Right AN
SPAKC0554AWZZ J SPAKC0659AWZZ J Packing Case AQ
TCAUA0012AWZZ J Not Used Caution Label, Operation Manual —
[For Taiwan Only]
TiNST0031AWZZ J TiNST0038AWZZ J Operation Manual [For Thailand] AF
TiNSZ0240AWZZ J TiNSZ0315AWZZ J Operation Manual [Except for Australia/ AK
New Zealand/Thailand]
TiNSZ0241AWZZ J TiNSZ0316AWZZ J Operation Manual [For Australia/New Zealand] AD
Not Used TLSTS0011AWZZ J S/S List AB
Not Used TLABG0002AWZZ J Label, Hong Kong AB
Not Used TLABH0047AWSA J Sheet, E/C Comparison A [For Taiwan Only] AH
Not Used TLABH0048AWSA J Sheet, E/C Comparison B [For Taiwan Only] AH
Not Used TLABH0049AWSA J Sheet, E/C Comparison C [For Taiwan Only] AH
Not Used TGANZ0022AW10 J Warranty Card [For Taiwan Only]
Not Used TMAPC0114AWZZ J Schematic Diagram AC
Not Used 92LGCARD1266E1 J Warranty Card [For Australia/New Zealand] AC
ACCESSORIES/PACKING PARTS
CP-C402
CP-C407
SECTION
Type 10 cm (4") full range speaker 2-way type [4" (10 cm) woofer
and super tweeter]
Dimensions Width; 170 mm (6-11/16") Width; 6-11/16" (170 mm)
Height; 280 mm (11") Height; 11-1/16" (280 mm)
Depth; 151 mm (5-15/16") Depth; 5-15/16" (151 mm)
Weight 1.4 kg (3.1 lbs.)/each 3.1 lbs. (1.4 kg)/each
DIFFERENCE BETWEEN CP-C402 AND CP-C407
REF.
NO.
CP-C407
PART NO.
701 92L121-0099 J 92L121-0151 J Net Frame Ass'y AU
702 92L051-0034 J 92L051-0064 J Speaker Box Ass'y AS
706 92L351-0170 J 92L351-0318 J Label, Specifications
SP3,4 Not Used 92L124-0016 J Super Tweeter Ass'y AK
SPEAKER BOX PARTS
DESCRIPTION
92L412-0072 J 92L412-0121 J Packing Add., Speaker (Top/Bottom)
92L353-0056 J 92L353-0080 J Feature Label
ACCESSORIES/PACKING PARTS
PART NO.
CD-C401W
CODE
PART NO.
CP-C402
CODE
To Next Page
