CD-C811W/821W
– 51 –
IC701 RH-iX0309AWZZ:System Microcomputer (IX0309AW) (2/2) (CD-C821W)
54 P120 T_T1T2 Output Tape T1/T2 change
55 P117 DISTO Input Distination input
56 P116 KEY JOG A Input Key jog input A
57 P115 KEY JOG B Input Key jog input B
58 P114 S MUTE Output System mute
59* P113 C MUTE Output Center mute
60* P112 SR MUTE Output Surround mute
61* P111 HI-CUT Output HI-Cut output
62 P110 POWER Output Power output
63* P107 SPRLY Output Speaker output relay control
64 P106 SP_DET Input Speaker output detection
65 P105 SPN_P Input Tuner span change
66 P104 DISTOUT Output Distination output
67 P103/FIP32 DIAS4/P22 Input Distination input
68 P102/FIP31 DIAS3/P21 Input Distination input
69 P101/FIP30 DIAS2/P15 Output FL Display segment driver
70 P100/FIP29 DIAS1/P16 Output FL Display segment driver
71-78 FIP28-FIP21 P18/P13-P11/P7 Output FL Display segment driver
79 VLOAD VLOAD — FL Driver (–) Power supp, –30V
80-89
P1-P5/P12/P17-19
P1-P5/P12/P17-P19 Output FL Display segment driver
90*,91* NC NC — Open terminal
92-100 G1-G9 G1-G9 Output FL Display segment driver
Port Name Terminal NamePin No. Input/Output
Function
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
To Next Page
