PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C811W/821W
C702 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic [821W]
C703,704 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
[811W Only]
C705 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic [811W]
C705 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic [821W]
C706 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic [821W]
C706 VCTYMN1EF223Z J AA 0.022 µF,25V [811W]
C707 VCCSMN1HL150J J AA 15 pF,50V [821W]
C707 VCEAZA0JW227M J AC 220 µF,6.3V,Electrolytic [811W]
C708 VCCSMN1HL180J J AA 18 pF,50V [821W Only]
C709 VCKZPA1HF223Z J AA 0.022 µF,50V [821W]
C709 VCTYPA1CX223K J AA 0.022 µF,16V [811W]
C710 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic [821W]
C710 VCKYPA1HB103K J AA 0.01 µF,50V [811W]
C711 VCKYPA1HB103K J AA 0.01 µF,50V [821W Only]
C712 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C713 VCKYPA1HF223Z J AB 0.022 µF,50V [811W]
C713 VCKZPA1HF223Z J AA 0.022 µF,50V [821W]
C714 VCTYMN1EF223Z J AA 0.022 µF,25V
C715 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C717 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
[821W Only]
C721 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
[821W Only]
C722 VCTYMN1EF223Z J AA 0.022 µF,25V [811W Only]
C773 VCTYPA1CX472K J AA 0.0047 µF,16V [811W Only]
C774 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
[811W Only]
C775 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[811W Only]
C901 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic [811W]
C901 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic [821W]
C902 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar [811W]
C902 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar [821W]
C903 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic [821W]
C903 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic [811W]
C904 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C905 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar [821W]
C905 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar [811W]
C906 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
C907 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic [811W]
C907 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic [821W]
C908~910 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C911 VCEAZW1EW338M J AG 3300 µF,25V,Electrolytic
C912 VCEAZW1HW228M J AH 2200 µF,50V,Electrolytic
C913 VCEAZV1EW108M J AE 1000 µF,25V,Electrolytic
C914 VCEAZA1EW107M J AB 100 µF,25V,Electrolytic
C915 VCEAZA1VW107M J AC 100 µF,35V,Electrolytic
C916~918 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C919,920 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C921,922 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C923,924 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C925 VCEAZA0JW108M J AC 1000 µF,6.3V,Electrolytic
C926 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C927 VCEAZA1EW477M J AD 470 µF,25V,Electrolytic
C928 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
! C929 RC-KZ001LAWZZ J AB 0.0047 µF,250V
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
VRS-TV2AB000J J AA 0 ohm,Jumper,1.25×2mm,Green
R1 VRS-TV2AB220J J AA 22 ohms,1/10W
R2 VRD-ST2CD102J J AA 1 kohm,1/6W
R8 VRS-TV2AB153J J AA 15 kohms,1/10W
R9 VRS-TV2AB104J J AA 100 kohm,1/10W
R10 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R11 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R12 VRD-ST2CD101J J AA 100 ohm,1/6W
R13 VRS-TV2AB102J J AA 1 kohm,1/10W
R14 VRS-TV2AB273J J AA 27 kohms,1/10W
R15 VRS-TV2AB123J J AA 12 kohms,1/10W
R16 VRS-TV2AB332J J AA 3.3 kohms,1/10W
R17 VRS-TV2AB333J J AA 33 kohms,1/10W
R18 VRS-TV2AB153J J AA 15 kohms,1/10W
R19 VRD-ST2CD102J J AA 1 kohm,1/6W
R20 VRS-TV2AB102J J AA 1 kohm,1/10W
R21 VRS-TV2AB152J J AA 1.5 kohms,1/10W
R22 VRS-TV2AB821J J AA 820 ohms,1/10W
R23 VRS-TV2AB103J J AA 10 kohm,1/10W
R24 VRS-TV2AB473J J AA 47 kohms,1/10W
R25 VRS-TV2AB152J J AA 1.5 kohms,1/10W
R26 VRS-TV2AB823J J AA 82 kohms,1/10W
R27 VRS-TV2AB393J J AA 39 kohms,1/10W
R28 VRS-TV2AB103J J AA 10 kohm,1/10W
R29 VRS-TV2AB563J J AA 56 kohms,1/10W
R30 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R31 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R32 VRS-TV2AB103J J AA 10 kohm,1/10W
R33 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R34 VRS-TV2AB102J J AA 1 kohm,1/10W
R35,36 VRS-TV2AB224J J AA 220 kohms,1/10W
R37 VRD-ST2CD823J J AA 82 kohms,1/6W
R38 VRS-TV2AB471J J AA 470 ohms,1/10W
R39 VRD-ST2CD102J J AA 1 kohm,1/6W
R40 VRS-TV2AB562J J AA 5.6 kohms,1/10W
R41,42 VRS-TV2AB473J J AA 47 kohms,1/10W
R43 VRS-TV2AB563J J AA 56 kohms,1/10W
R44 VRS-TV2AB333J J AA 33 kohms,1/10W
R45 VRS-TV2AB472J J AA 4.7 kohms,1/10W
R46 VRS-TV2AB561J J AA 560 ohms,1/10W
R47 VRD-ST2CD103J J AA 10 kohm,1/6W
R50 VRS-TV2AB681J J AA 680 ohms,1/10W
R51 VRD-ST2CD335J J AA 3.3 Mohms,1/6W
R52 VRS-TV2AB273J J AA 27 kohms,1/10W
R53 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R55 VRD-ST2CD101J J AA 100 ohm,1/6W
R56 VRS-TV2AB223J J AA 22 kohms,1/10W
R57 VRD-ST2CD102J J AA 1 kohm,1/6W
R58~60 VRS-TV2AB102J J AA 1 kohm,1/10W
R61~63 VRD-ST2CD102J J AA 1 kohm,1/6W
R64 VRS-TV2AB220J J AA 22 ohms,1/10W
R65 VRD-ST2CD102J J AA 1 kohm,1/6W
R66 VRS-TV2AB221J J AA 220 ohms,1/10W
R71,72 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R73,74 VRS-TV2AB104J J AA 100 kohm,1/10W
R80,81 VRD-ST2CD821J J AA 820 ohms,1/6W
R82,83 VRS-TV2AB391J J AA 390 ohms,1/10W
R84 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R88,89 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R90 VRD-ST2CD221J J AA 220 ohms,1/6W
R91 VRD-ST2CD102J J AA 1 kohm,1/6W
R93 VRS-TV2AB221J J AA 220 ohms,1/10W
R323 VRD-MN2BD683J J AA 68 kohms,1/8W
R336 VRD-ST2CD102J J AA 1 kohm,1/6W
R344 VRD-MN2BD471J J AA 470 ohms,1/8W
R345 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R350 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R351 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R352 VRD-MN2BD102J J AA 1 kohm,1/8W
R353 VRD-MN2BD271J J AA 270 ohms,1/8W
R354 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R355 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R356 VRD-MN2BD102J J AA 1 kohm,1/8W
R357 VRD-ST2CD474J J AA 470 kohms,1/6W
R358 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R359 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R360 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R361,362 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R363,364 VRD-MN2BD473J J AA 47 kohms,1/8W
R365,366 VRD-MN2BD103J J AA 10 kohm,1/8W
R367 VRD-MN2BD102J J AA 1 kohm,1/8W
R368 VRD-ST2CD333J J AA 33 kohms,1/6W
R369 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R371~374 VRD-MN2BD102J J AA 1 kohm,1/8W
R375 VRD-ST2EE680J J AA 68 ohms,1/4W
R376 VRD-MN2BD102J J AA 1 kohm,1/8W
R377 VRD-ST2CD473J J AA 47 kohms,1/6W
R378 VRD-MN2BD823J J AA 82 kohms,1/8W
R379 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R380 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R381 VRD-MN2BD103J J AA 10 kohm,1/8W
R382 VRD-ST2EE151J J AA 150 ohms,1/4W
R383~385 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R387 VRD-MN2BD223J J AA 22 kohms,1/8W
R391,392 VRD-ST2EE391J J AA 390 ohms,1/4W
R393 VRD-ST2CD102J J AA 1 kohm,1/6W
R395 VRD-ST2CD473J J AA 47 kohms,1/6W
R398 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R401 VRD-MN2BD331J J AA 330 ohms,1/8W
R402 VRD-ST2CD331J J AA 330 ohms,1/6W
R403,404 VRD-MN2BD103J J AA 10 kohm,1/8W [821W Only]
R405 VRD-MN2BD222J J AA 2.2 kohms,1/8W [811W]
R405 VRD-ST2CD222J J AA 2.2 kohms,1/6W [821W]
– 3 –
