System connections
3
3
2
2
AM loop aerial
FM aerial
Red
Black
Front speaker (Right)
Front speaker (Left)
Wall socket
(AC 230 V, 50 Hz)
RCA lead
(not supplied)
To the line
output sockets
VCR, DVD, etc.
TV
Centre speaker
Surround speaker
(Right)
Surround speaker
(Left)
Grey
Orange
Centre speaker
Surround speaker
(Right)
Surround speaker
(Left)
Front speaker
(Right)
Front speaker
(Left)
