PART NAMES
1
Air Outlet
2
Vertical louvers
3
Horizontal louvers
4
Remote control signal receiver
window
5
POWER Button
6
OPERATION Lamp (red)
7
TIMER Lamp (orange)
8
MEGA COOL Lamp (green)
9
Air inlet
REAR VIEW
NOTE: Actual unit might vary slightly from above illustration.
FRONT VIEW
0
Exhaust air outlet
q
Window exhaust adapter
w
Exhaust hose
e
Remote control hook
r
Air fi lters
t
Drainage nozzle and stopcock
y
Power supply cord hooks
u
Drainpipe nozzle and stopcock
i
Power supply cord
o
Power plug
p
Casters(4)
