Sharp CV-P09LX User Manual

CVP09LX
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] CV-P09LX (Outside parts)
1-1 CCAB-A421JBKZ BH Cabinet ass'y
1-2 GCAB-A292JBFA BL Cabinet
1-3 LHLD-A735JBFA AD Cord holder
1-4 TLAB-C990JBRZ AF Caution label
1-5 TLAB-C973JBRZ AF Caution label
1-6 TLAB-C974JBRZ AF Label
1-7 TLAB-C975JBRZ AF Label
1-8 TLAB-C976JBRZ AF Caution label
1-36 CPNL-A55 3JBKZ BH Front panel ass'y
1-37 HBDG-A002KKEA AE Al badge
1-38 HDEC-B192JBFA AF Cluster display
1-39 HPNL-A726JBFA AW Center panel
1-40 HPNL-A727JBFA AZ Display panel
1-41 HPNL-A815JBRA BC Front panel
1-42 PGID-A124JBFA AF Filter guide A
1-43 PGID-A125JBFA AF Filter guide B
1-55 CKITTA069AKKZ BD Plasmacluster unit
1-56 DLOV-A013 JBKZ AZ H louver ass'y
1-57 MLOV-A413JBFA AF Horizontal louver C
1-58 MLOV-A412JBFA AF Horizontal louver B
1-59 GWAKPA173JBFA BC Top duct
1-60 LANG-A623JBPZ AG Top angle
1-61 LHLD-A737JBFA AZ Cluster holder
1-62 LSTP-A02 7JBFA AM Stopper
1-63 MLOV-A411JBFA AF Horizontal louver A
1-64 PCOV-B108JBFA AZ Cluster cover
1-65 PFPFPC769JBFZ AF Insulator A
1-66 PFPFPC770JBFZ AF Insulator B
1-67 PFPFPC771JBEZ AF Insulator C
1-68 PFPFPC772JBEZ AF Insulator D
1-69 PFPFPC773JBEZ AF Insulator E
1-70 PFPFPC774JBEZ AF Insulator F
1-71 PFPFPC775JBEZ AF Insulator G
1-72 PFPFPC830JBEZ AC
Cl.cover insulator B
1-73 PFPFPC831JBEZ AC Cl.cover insulator D
1-74 PFPFPC832JBEZ AC Insulator H
1-75 PFPFPC862JBEZ AC Insulator I
1-76 PSEL-C876JBEZ AC Cluster insulator
1-77 PSEL-C877JBEZ AC Cl.cover insulator A
1-78 PSEL-C879JBEZ AC Cl.cover insulator C
1-79 PSPRCA018JBEZ AF Spring
1-80 QW-VZF4 19JBZZ AF Lead wire
1-81 RMOT-A061JBE0 AS Louver motor
1-83 DFILMA001JBEA AM Ply filter A
1-84 DFILMA002JBEA AM Ply filter B
1-115 HPNL-A728JBFA AW Side panel L
1-116 HPNL-A729JBFA AW Side panel R
1-132 TLAB-C977JBRZ AF Caution label
1-134 TSPC-F428JBRZ AK Name badge
1-137 TLAB-C990JBRZ AF Caution label EN
6-16 XTPS730P10000 AC Tapping screw
6-19 XTTS740P12 000 AC Tapping screw
6-22 XUPS740P08000 AC Tapping screw
6-24 XTTS740P10 000 AC Tapping screw
