58
An AC sine wave voltage of 100V, 60Hz is applied to a circuit consisting of a resistor
(R = 120 ), coil (L = 4 H), and capacitor (C = 3 x 10
-6
F) connected in series.
(1) Find the impedance of the circuit.
(2) Find the phase difference between the current and the voltage.
Circuit impedance = Value of polar coordinate r
(rectangular coordinates)
(Angle units: DEG)
(Polar coordinates)
(DEG)
Operation
120
3
2
2
60
1
6
4
60
i
i
Phase difference = Polar coordinate
Let R = 120, L = 4, C = 3 x 10
-6
, and f = 60. If the complex number
Z = R + 2 fLi + 1 (2 fCi), find the value of the complex number Z and
the values of r and .
Display
Complex Calculation
<Example 2>
i
(This example is for EL-W516T only.)
<Complex mode>
(COMPLEX)
(DRG)
