40
KB-6025MS
KB-6025MK
KB-6025MW
MICROWAVE DRAWER PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
3- 1 RTRN-B084MRE0 M Transformer 1 BE
3- 2 RV-MZA288WRE0 M Magnetron 1 BK
3- 3 FDTCTA234WRKZ M Sensor assy 1 AP
3- 4 FFS-BA018/KIT M Monitor switch (V-16G-2C25) with fuse (20A) assembly 1 AF
3- 5 TMAPCB110MRR0 M Schematic 1 AB
3- 6 TCAUAB050MRR0 M Monitor caution label 2 AD
3- 7 LHLD-B034MRF0 M Power supply unit holder 1 AC
3- 8 DPWBFB137MRU0 M Power supply 2 AZ
3- 9 LANGTB122MRP0 M Oven lamp angle 1 AK
3-10 LX-CZ0052WRE0 M Screw/washer 6 AA
3-11 GCABDB012MRP0A M Back plate [KB6024MS/MK/MW] 1 AU
3-11 GCABDB006MRP0 M Back plate [KB6025MS/MK/MW] 1 AW
3-12 PDUC-B141MRP0 M Mag duct 1 AE
3-13 PDUC-B142MRP0A M Sensor duct 1 AK
3-14 PDUC-B161MRP0A M Exhaust duct A [KB6024MS/MK/MW] 1 AK
3-14 PDUC-B004MRP0 M Exhaust duct A [KB6025MS/MK/MW] 1 AL
3-15 PDUC-B162MRP0 M Exhaust duct B [KB6024MS/MK/MW] 1 AH
3-15 PDUC-B148MRP0 M Exhaust duct B [KB6025MS/MK/MW] 1 AF
3-16 FCOVPB052MRY0 M Stir cover assy 1 AR
3-17 PCLICB003MRE0 M Canoe clip 3 AB
3-18 MSLIFB001/KIT M Slide rail 3 AV
3-19 LANGTB120MRT0 M Door support angle A 2 AK
3-20 LANGTB211MRT0 M Door support angle B 1 AB
3-21 GCOVHB060MRF0 M Door support cover 2 AH
3-22 PSKR-B018MRP0 M Magnetron air guide 1 AC
3-23 PFILWB005MRP0 M Lamplter 1 AB
3-24 PDUC-B162MRP0 M Partition angle [KB6024MS/MK/MW] 1 AH
3-24 LANGTB076MRP0A M Partition angle [KB6025MS/MK/MW] 1 AB
3-25 FC-QZB052MRK0A M HVC assy 1 AP
3-26 LBNDKB007MRP0 M HVC band 1 AB
3-27 XCBS730P08000 M Screw 3 AB
3-28 XOTS740P12000 M Screw 79 AA
3-29 PCOVPB169MRP0A M Top cover [KB6024MS/MK/MW] 1 AE
3-29 PCOVPB142MRP0 M Top cover [KB6025MS/MK/MW] 1 AW
3-30 TLAB-B063MRR0 M Menu label 1 AD
3-31 XOTS740P12RV0 M Screw 4 AB
3-32 XEPS730P10XS0 M Power unit assy screw 2 AC
3-33 DDORFB128MRK0 M Door assy [KB6024MS] 1 BU
3-33 DDORFB120MRK0 M Door assy [KB6024MK] 1 BS
3-33 DDORFB121MRK0 M Door assy [KB6024MW] 1 BS
3-33 DDORFB098MRK0 M Door assy [KB6025MS] 1 BU
3-33 DDORFB102MRK0 M Door assy [KB6025MK] 1 BU
3-33 DDORFB103MRK0 M Door assy [KB6025MW] 1 BU
3-34 PSHEPB184MRE0 M Sealerlm 1 AQ
3-35 FFAN-B008MRK0 M Stirrer fan assy 1 AK
3-36 FANGTB015MRK0 M Latch angle assy R [KB6024MS/MK/MW] 1 AL
3-37 FANGTB016MRK0 M Latch angle assy L [KB6024MS/MK/MW] 1 AL
3-36 FANGTB010MRK0 M Latch angle assy R [KB6025MS/MK/MW] 1 AH
3-37 FANGTB011MRK0 M Latch angle assy L [KB6025MS/MK/MW] 1 AH
3-38 GCABUB158MRP0A M Side cabinet L [KB6024MS/MK/MW] 1 AN
3-39 GCABUB157MRP0A M Side cabinet R [KB6024MS/MK/MW] 1 AN
3-38 GCABUB146MRP0A M Side cabinet L [KB6025MS/MK/MW] 1 AU
3-39 GCABUB145MRP0A M Side cabinet R [KB6025MS/MK/MW] 1 AU
3-40 PCOVPB143MRP0 M Air cover 1 AE
3-41 LX-NZB006MRE0 M Cap nut 6 AA
3-42 XHTS740P08000 M Screw 4 AA
3-43 TCAUKB001MRR0 M Stirrer cover cleaning label 1 AA
3-44 FMOTEA499WRKZ M Fan motor 1 AY
3-45 LANGTB155MRP0 M Fan motor angle 1 AK
3-46 RTHM-A135WRZZ M Thermal cut-out 2 AD
3-47 FW-VZB312MRE0 M Harness assy [KB6024MS/MK/MW] 1 AW
3-47 FW-VZB267MRE0 M Harness assy [KB6025MS/MK/MW] 1 AV
∆
*
