7
QUICK INSTALLATION TIPS
1
Attach your antenna to the back of the TV.
(See page 12.)
2
Connect the AC plug for the TV into the wall outlet.
• Place the TV close to the AC outlet, and keep the power
plug within reach.
NOTE
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT
TOUCH UN-INSULATED PARTS OF ANY CABLES
WITH THE AC CORD CONNECTED.
3
Secure cables and cords with the supplied cable tie so
that they do not get caught when mounting the cover.
4
How to turn on the TV for the first time.
A) Press POWER on TV.
B) POWER indicator on the front of the TV lights GREEN.
NOTE
• Speaker cannot be detached from the TV.
• TV angle cannot be adjusted.
AC outlet
QUICK REFERENCE
POWER
POWER indicator
Cable tie
37N0131B.indb 737N0131B.indb 7 5/9/09 9:25:12 AM5/9/09 9:25:12 AM
