Sharp LC-19SK24U

111
Ref. No. Part No.
★
Description Code Ref
. No. Part No.
★
Description Code
LC-19SK24U/U-W
LC-19SB24U/U-W
LC-19SB14U
LC-19D44U
HM7509 LX-GZ3001PEZZ J Screw AB
HM7510 LX-GZ3001PEZZ J Screw AB
HM7511 LX-GZ3002PEZZ J Screw AB
HM7512 LX-GZ3002PEZZ J Screw AB
HM7513 LX-GZ3002PEZZ J Screw AB
HM7514 LX-GZ3002PEZZ J Screw AB
HM7515 LX-GZ3002PEZZ J Screw AB
HM7516 LX-GZ3002PEZZ J Screw AB
HM7517 LX-GZ3002PEZZ J Screw AB
HM7518 LX-GZ3002PEZZ J Screw AB
HM7519 LX-GZ3002PEZZ J Screw AB
HM7520 LX-GZ3002PEZZ J Screw AB
P7501 QPLGNA391WJZZ J Plug (to Panel) AD
P7502 QPLGNA391WJZZ J Plug (to Panel) AD
P7503 QPLGNA056WJZZ J Plug (to Panel) AB
P7504 QPLGNA056WJZZ J Plug (to Panel) AB
!
SC7501 QCNCMA012WJZZ J Connector (to Main) AD
SG7501 QSPGCA009WJZZ J Spar
k Gap AG
TH7501 RH-HXA019WJZZ J Ntpad3R9Ldnb0 AE
RDA7501 PRDARA486WJFW J Heat Sink-A AF
RDA7502 PRDARA487WJFW J Heat Sink-B AF
XBBS930P06000 J Screw (for heat sink), x2 AA
LANGTA469WJFW J Fixing Metal AF
PSPAHB360WJ00 J Spacer AA
XBPSN30P06000 J Screw (for AC Angle) AA
DUNTKE367FM01
MAIN UNIT
INTEGRATED CIRCUITS
IC301 VHINJM2750M-1Y J NJM2750M(TE2) AH
IC302 VHIWM8983++-1Y J WM8983GEFL/RV AQ
IC303 VHIYDA147SZ-1Y J YDA147-SZE2 AM
IC304 VHI7WH157FK-1Y J TC7WH157FK(TE85L,F) AF
IC305 VHIT7PAU04U-1Y J TC7PAU04FU(TE85L,F AD
IC306 VHIAHC1G08W-1Y J 74AHC1G08GW/G,125 AD
IC401 VHIBR24C21F-1Y J BR24C21F-E2 AG
IC402 VHINC7WZ14P-1Y J NC7WZ14P6X AD
IC403 VHIBR24L02F1EY J BR24L02F-WE2 AE
IC405 VHINC7WZ14P-1Y J NC7WZ14P6X AD
IC701 VHIPQ200WNA-1Y J PQ200WNA1ZPH AG
IC702 VHIPQ1LAX95-1Y J PQ1LAX95MSPQ AD
IC703 VHIMP1415C+-1Y J MP1415DSE-C100-LF-Z AK
IC704 VHIMM3203B+-1Y J MM3203BFBE AG
IC705 VHIMP2259++-1Y J MP2259DJ-LF-Z AK
IC801 RH-IXB882WJZZQ J R8J66612A04BG BG
IC802 VHIAHC1G08W-1Y J 74AHC1G08GW/G,125 AD
IC803 VHIS24CS64A-1Y J S-24CS64AOI-J8T1G AF
IC1001 VHINJM2902V-1Y J NJM2902V(TE1) AD
IC2001 VHIPST8229N-1Y J IC-PST8229NR AC
IC2002 RH-IXC165WJZZQ J R5F212A8SNFP AQ
IC2003 VHIBR24L04F-1Y J BR24L04F-WE2 AE
IC2004 VHIPQ1LAX95-1Y J PQ1LAX95MSPQ AD
IC2006 VHIAHC1G08W-1Y J 74AHC1G08GW/G,125 AD
IC8701 VHIPQ025ENA-1Y J PQ025ENA1ZPH AE
IC8702 VHIMST3383D-1Q J MST3383MK-LF-170 AV
IC9201 RH-IXC209WJZZQ J IXC209WJ AN
IC9202 VHINJM2904V-1Y J NJM2904V-TE1 AF
TRANSISTORS
Q301 VSDTC614TK+-1Y J DTC614TK AB
Q302 VSDTC614TK+-1Y J DTC614TK AB
Q303 VS2SC3928AR-1Y J 2SC3928AR AB
Q401 VSRT1N441U/-1Y J RT1N441U AB
Q403 VSRT1N441U/-1Y J RT1N441U AB
Q404 VSRT1N441U/-1Y J RT1N441U AB
Q701 VSRTQ035P02-1Y J RTQ035P02 AD
Q702 RH-TXA028WJZZY J TXA028WJ AC
Q703 VSRT1N144U/-1Y J RT1N144U AB
Q704 VSRT1N141U/-1Y J RT1N144U AB
Q705 VS2SC5383F/-1Y J 2SC5383F AB
Q706 VS2SA1037KQ-1Y J 2SA1037K AA
Q801 VS2SC3928AR-1Y J 2SC3928AR AB
Q802 VSRT1P441U/-1Y J RT1N441U AB
Q803 VS2SC3928AR-1Y J 2SC3928AR AB
Q805 VS2SC3928AR-1Y J 2SC3928AR AB
Q807 VSRT1N441U/-1Y J RT1N441U AB
Q808 VSRT1N441U/-1Y J RT1N441U AB
Q809 VSRDTC143ZE-1Y J PDTC143ZE AB
Q810 VSRT1P441U/-1Y J RT1N441U AB
Q908 VS2SC3928AR-1Y J 2SC3928AR AB
Q2001 VSRDTC143ZE-1Y J PDTC143ZE AB
Q2002 VS2SA1037KQ-1Y J 2SA1037K AA
Q2003 VSRT1N141U/-1Y J RT1N144U AB
Q2004 VSIMZ1A////-1Y J IMZ1AT108 AC
Q8703 VSUM6K1NTN+-1Y J UM6K1NTN AC
DIODES
D303 VHD1PS184++-1Y J Diode AB
D304 RH-EX0262TAZZY J Zener Diode, 7.5V AB
D309 VHD1PS184++-1Y J Diode AB
D310 VHD1PS184++-1Y J Diode AB
D406 VHD1PS184++-1Y J Diode AB
D411 VHD1PS184++-1Y J Diode AB
D701 VHDDG1M3+++-1Y J Diode AC
D702 VHDKDS4148/-1Y J Diode AA
D703 VHDKDS4148/-1Y J Diode AA
D704 VHDDG1M3+++-1Y J Diode AC
D801 VHD1PS184++-1Y J Diode AB
D2002 VHDKDS4148/-1Y J Diode AA
PACKAGED CIRCUITS
X301 RCRSCA161WJQZY J Crystal AE
X802 RCRSCA101WJZZY J Crystal AG
X803 RCRSCA147WJZZY J Crystal AG
X8701 RCRSCA134WJZZY J Crystal AE
COILS
L301 RCILPA950WJZZY J Coil AD
L302 RCILPA950WJZZY J Coil AD
L303 RCILPA950WJZZY J Coil AD
L304 RCILPA950WJZZY J Coil AD
L701 RCILPA085WJZZY J Coil AD
L702 VPCBM330K1R7NY J Peaking 33µH AC
L703 VPCBM330K1R7NY J Peaking 33µH AC
L704 RCILPA192WJZZY J Coil AC
L705 VPCEM470M3R7NY J Peaking 47µH AC
FILTER
FL2001 RFILZA003WJPZY J Filter AD
CAPACITORS
C301 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C302 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C303 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C304 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C305 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C306 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C307 VCKYCY1AB105KY J 1 10V Ceramic AB
C308 VCKYCY1AB105KY J 1 10V Ceramic AB
C309 VCKYCY1AB105KY J 1 10V Ceramic AB
C310 VCKYCY1AB105KY J 1 10V Ceramic AB
C311 VCKYCZ1EB103KY J 0.010 25V Ceramic AA
C312 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C313 RC-KZA237WJZZY J 10 16V Ceramic AB
C314 RC-KZA067WJZZY J 4.7 10V Ceramic AB
C315 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C316 VCKYCZ1AB104KY J 0.10 10V Ceramic AB
C317 RC-KZA067WJZZY J 4.7 10V Ceramic AB
C318 RC-KZA067WJZZY J 4.7 10V Ceramic AB
C330 VCKYCY1AB105KY J 1 10V Ceramic AB
C331 VCKYCY1AB105KY J 1 10V Ceramic AB
C333 RC-KZA195WJZZY J 10µF 10V Ceramic AB
C334 VCKYCY1AB105KY J 1 10V Ceramic AB
DUNTKE333FM01
POWER INVERTER UNIT (Continued)
